Panasonic CS-Z42XKEW Service Manual

17
Model
Indoor CS-Z25XKEW, CS-XZ25XKEW
Outdoor CU-Z25XKE
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (6-poles)
Output Power W 550
Indoor Fan
Type Cross-flow fan
Material ASG30
Motor Type DC (8-pole)
Input Power W 47.1
Output Power W 30
Speed
QLo
Cool rpm 500
Heat rpm 510
Lo
Cool rpm 610
Heat rpm 670
Me
Cool rpm 770
Heat rpm 850
Hi
Cool rpm 920
Heat rpm 1010
SHi
Cool rpm 980
Heat rpm 1070
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-pole)
Input Power W -
Output Power W 40
Speed Hi
Cool rpm 820
Heat rpm 780
Moisture Removal L/h (Pt/h) 1.5 (3.2)
Indoor Airflow
QLo
Cool m³/min (ft³/min) 5.94 (210)
Heat m³/min (ft³/min) 6.10 (215)
Lo
Cool m³/min (ft³/min) 7.71 (272)
Heat m³/min (ft³/min) 8.68 (306)
Me
Cool m³/min (ft³/min) 10.28 (363)
Heat m³/min (ft³/min) 11.57 (409)
Hi
Cool m³/min (ft³/min) 12.70 (450)
Heat m³/min (ft³/min) 14.10 (500)
SHi
Cool m³/min (ft³/min) 13.66 (482)
Heat m³/min (ft³/min) 15.11 (534)
Outdoor Airflow Hi
Cool m³/min (ft³/min) 28.70 (1015)
Heat m³/min (ft³/min) 27.20 (960)
Refrigerant Cycle
Control Device Expansion Valve
Refrigerant Oil cm³ FW50S (270)
Refrigerant Type kg (oz) R32, 0.80 (28.2)
F-Gas
GWP 675
CO2eq (ton)
(Precharge Amount / Maximum Charged Amount)
0.54 / 0.59
