SAFETY REF. NO. PART NAME & DESCRIPTION QTY CS-Z25UFEAW CS-Z35UFEAW REMARK
1 CHASSIS-COMPLETE 1 ACXD50C01620 ←
2 FAN MOTOR BRACKET (BOTTOM) 1 ACXD54-01370 ←
3 FAN MOTOR BRACKET (TOP) 1 ACXD54-01380 ←
4 FAN MOTOR 1 L6CBYYYL0253 ← O
5 SCREW-BRACKET FAN MOTOR 2 XTN4+12CFJ ←
6 CROSS-FLOW FAN-COMPLETE 1 ACXH02C00850 ←
7 EVAPORATER COMPLETE 1 ACXB30C17950 ←
8 FLARE NUT (LIQUID) 1 CWT251048 ←
9 FLARE NUT (GAS) 1 CWT251049 ←
10 PARTICULAR PIECE -TERMINAL 1 ACXD93-15770 ←
11 TERMINAL BOARD-COMPLETE 1 ACXA28C05290 ←
12 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C41790 ACXA73C41800 O
13 ELECTRONIC CONTROLLER - INDICATOR 1 ACXA73-19200 ← O
14 INDICATOR HOLDER 1 ACXD93-10910 ←
15 ELECTRONIC CONTROLLER - RECEIVER 1 ACXA73-19210 ← O
16 SENSOR-CO. (PIPING AND SUCTION TEMP) 1 ACXA50C13490 ←
17 DISCHARGE GRILLE-COMPLETE 1 ACXE20C02960 ←
18 WIRE NET 1 ACXD04-00980A ←
19 FULCRUM 1 ACXH62-00470 ←
20 SHAFT 2 ACXH63-01090 ←
21 AIR SWING MOTOR (FRONT) 1 CWA981264 ← O
22 AIR SWING MOTOR (TOP) 1 CWA981299 ← O
23 SHAFT 2 ACXH63-01340 ←
24 VERTICAL VANE 8 ACXE24-02100 ←
25 VERTICAL VANE 2 ACXE24-02110 ←
26 CONNECTING BAR 2 ACXE26-01530 ←
27 HORIZONTAL VANE 1 ACXE24-02070 ←
28 PARTICULAR PIECE 1 ACXD93-16690 ←
29 GENERATOR COMPLETE 1 ACXH94C00580 ← O
30 DUCT-COMPLETE 1 ACXD22C00190 ←
31 CONTROL BOARD COVER-COMPLETE 1 ACXH13C05030 ←
32 DRAIN PAN-COMPLETE 1 ACXH40C00700 ←
33 FLEXIBLE PIPE 1 ACXH85-02890 ←
34 FRONT GRILLE-COMPLETE 1 ACXE10C06700 ←
35 SELF TAPPING SCREW-FRONT GRILLE 2 XTT4+16CFJ ←
36 VANE-COMPLETE 1 ACXE24C02790 ←
37 GRILLE DOOR-COMPLETE 1 ACXE14C00960 ←
38 INTAKE GRILLE-COMPLETE 1 ACXE22C02330 ←
38A LOCK-INTAKE GRILLE 2 ACXD93-10630 ←
39 STRING-COMPLETE 1 ACXH84C00190 ←
40 AIR FILTER 2 ACXD00-01370 ←
41 REMOTE CONTROL COMPLETE 1 ACXA75C13500 ← O
42 OPERATING INSTRUCTION 1 ACXF55-19350 ←
43 OPERATING INSTRUCTION 1 ACXF55-19360 ←
44 OPERATING INSTRUCTION 1 ACXF55-19370 ←
45 OPERATING INSTRUCTION 1 ACXF55-20140 ←
46 INSTALLATION INSTRUCTION 1 ACXF60-28280 ←
