Multi Split Combination Possibility:
o A single outdoor unit enables air conditioning of up to two separate rooms for CU-2Z35TBE, CU-2Z41TBE,
CU-2Z50TBE.
CONNECTABLE INDOOR UNIT CU-2Z35TBE CU-2Z41TBE CU-2Z50TBE
ROOM A B A B A B
Wall
2.0kW CS-MZ20UFEA ● ● ● ● ● ●
2.5kW CS-Z25UFEAW ● ● ● ● ● ●
3.5kW CS-Z35UFEAW ● – ● – ● ●
5.0kW CS-Z50UFEAW – – – – ● –
Capacity range of connectable units From 3.2kW to 6.0kW From 3.2kW to 6.0kW From 3.2kW to 7.7kW
Pipe length
1 room maximum pipe length (m) 20 20 20
Allowable elevation (m) 10 10 10
Total allowable pipe length (m) 30 30 30
Total pipe length for maximum
chargeless length (m)
20 20 20
Additional gas amount over
chargeless length (g/m)
15 15 15
Note: “●” : Available
Remarks for CU-2Z35TBE / CU-2Z41TBE / CU-2Z50TBE
1. The total nominal cooling capacity of indoor unit that will be connected to outdoor unit must be within connectable capacity range of indoor
unit. (as shown in the table above)
Example: The indoor units’ combination below is possible to connect to CU-2Z41TBE. (Total nominal capacity of indoor units is between
3.2kW to 6.0kW)
1) Two CS-MZ20UFEA only. (Total nominal cooling capacity is 4.0kW)
To Next Page
