 Heating Characteristic
[Condition] Room temperature: 68°F (DBT)
Operation condition: High fan speed
Piping Length: 24.6ft
Compressor Freq: Fh
B) Indoor unit capacity: Heating (3.2 + 3.2: CS-E12NKUAW + CS-E12NKUAW), service mode frequency = 63Hz
83.000
88.000
93.000
98.000
103.000
108.000
113.000
118.000
3 8 13 18 23 28 33 38 43 48 53 58 63 68 73 78
Outdoor Air Temperature (°F)
Outlet Air
Temperature (°F
)
208 230
3.100
4.100
5.100
6.100
7.100
8.100
9.100
3 8 13 18 23 28 33 38 43 48 53 58 63 68 73 78
Outdoor Air Temperature (°F)
Heating
Capacity (kW)
6.000
6.500
7.000
7.500
8.000
8.500
9.000
9.500
10.000
3 8 13 18 23 28 33 38 43 48 53 58 63 68 73 78
Outdoor Air Temperature (°F)
Current
(A)
45.000
55.000
65.000
75.000
85.000
95.000
105.000
115.000
125.000
135.000
145.000
155.000
3 8 13 18 23 28 33 38 43 48 53 58 63 68 73 78
Outdoor Air Temperature (°F)
Gas Side Piping
Pressure (PSI)
