Air
Circulation
Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber
20%
AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 29.3 - 26.3 121.82 - 107.91
Rated Output W 15 37
Fan Speed Low rpm 780 - 780 —
Medium rpm 920 - 920 —
High rpm 1,140 - 1,140 765 - 725
SuperHigh rpm 1,250 - 1,250 —
Heat
Exchanger
Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 15 2 × 24
FPI 19 16
Size (W × H × L) mm 610 × 315 × 25.4 756.0
719.5
× 609.6 × 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60 (320, 270)
Refrigerant (R-22) g (oz) — (A unit) 800 (28.2)
(B unit) 1,070 (37.7)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary
Tube
Length mm — 935, 920, 1,170
Flow Rate l/min — 20.0, 15.5, 10.0
Inner Diameter mm — 2.0, 1.8, 1.6
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 25 µF, 440 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 3.0 µF, 450 VAC
•
Specifications are subject to change without notice for further improvement.
11
CS-C9BKPG CU-2C14BKP5G / CS-C9BKPG CU-2C18BKP5G / CS-C9BKPG CU-3C20BKP5G / CS-C7BKPG CU-2C19BKP5G / CS-C12BKPG
