Panasonic CU-3C20BKP5G Service Manual

230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.57 2.71 1.11 3.34 2.60 1.19 3.10 2.49 1.28 2.82 2.37 1.38
19.0°C 3.60 1.21
19.5°C 3.92 2.83 1.13 3.66 2.72 1.21 3.41 2.62 1.30 3.10 2.50 1.40
22.0°C 4.27 2.94 1.15 3.99 2.83 1.24 3.72 2.73 1.32 3.38 2.60 1.43
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.49 2.65 1.05 3.26 2.54 1.13 3.03 2.44 1.21 2.76 2.32 1.31
19.0°C 3.52 1.15
19.5°C 3.83 2.77 1.07 3.58 2.66 1.15 3.33 2.56 1.24 3.03 2.44 1.33
22.0°C 4.18 2.87 1.09 3.90 2.76 1.18 3.63 2.67 1.26 3.30 2.54 1.36
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.18 3.93 1.69 4.84 3.76 1.82 4.50 3.62 1.95 4.09 3.44 2.10
19.0°C 5.22 1.85
19.5°C 5.68 4.11 1.73 5.31 3.95 1.86 4.94 3.80 1.99 4.49 3.62 2.14
22.0°C 6.20 4.26 1.76 5.79 4.10 1.89 5.39 3.95 2.02 4.90 3.77 2.18
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.08 3.85 1.60 4.75 3.69 1.72 4.41 3.55 1.84 4.01 3.37 1.99
19.0°C 5.12 1.75
19.5°C 5.58 4.03 1.63 5.21 3.87 1.76 4.85 3.73 1.88 4.41 3.55 2.03
22.0°C 6.08 4.18 1.66 5.68 4.02 1.79 5.28 3.88 1.91 4.80 3.70 2.06
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.95 4.51 1.76 5.56 4.33 1.89 5.17 4.16 2.02 4.70 3.95 2.18
19.0°C 6.00 1.92
19.5°C 6.53 4.72 1.79 6.11 4.54 1.93 5.68 4.37 2.06 5.17 4.16 2.22
22.0°C 7.12 4.90 1.82 6.65 4.71 1.96 6.19 4.54 2.10 5.63 4.33 2.26
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.81 4.41 1.69 5.43 4.23 1.81 5.05 4.06 1.94 4.59 3.86 2.09
19.0°C 5.86 1.84
19.5°C 6.38 4.61 1.72 5.97 4.43 1.85 5.55 4.27 1.98 5.05 4.06 2.13
22.0°C 6.96 4.79 1.75 6.50 4.60 1.88 6.05 4.44 2.01 5.50 4.23 2.17
67
CS-C9BKPG CU-2C14BKP5G / CS-C9BKPG CU-2C18BKP5G / CS-C9BKPG CU-3C20BKP5G / CS-C7BKPG CU-2C19BKP5G / CS-C12BKPG
