Panasonic CU-3C20BKP5G Service Manual

230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.52 2.67 1.15 3.29 2.56 1.23 3.06 2.46 1.32 2.78 2.34 1.42
19.0°C 3.55 1.25
19.5°C 3.87 2.80 1.17 3.61 2.69 1.26 3.36 2.59 1.34 3.06 2.46 1.45
22.0°C 4.21 2.90 1.19 3.94 2.79 1.28 3.66 2.69 1.37 3.33 2.56 1.47
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.49 2.65 1.13 3.26 2.54 1.21 3.03 2.44 1.30 2.76 2.32 1.40
19.0°C 3.52 1.23
19.5°C 3.83 2.77 1.15 3.58 2.66 1.23 3.33 2.56 1.32 3.03 2.44 1.42
22.0°C 4.18 2.87 1.17 3.90 2.76 1.26 3.63 2.67 1.34 3.30 2.54 1.45
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 2.06 1.56 0.69 1.93 1.50 0.74 1.79 1.44 0.79 1.63 1.37 0.85
19.0°C 2.08 0.75
19.5°C 2.27 1.64 0.70 2.12 1.57 0.75 1.97 1.51 0.81 1.79 1.44 0.87
22.0°C 2.47 1.70 0.71 2.31 1.63 0.77 2.15 1.58 0.82 1.95 1.50 0.88
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 2.04 1.55 0.66 1.91 1.49 0.71 1.78 1.43 0.76 1.62 1.36 0.82
19.0°C 2.06 0.72
19.5°C 2.24 1.62 0.67 2.10 1.56 0.72 1.95 1.50 0.77 1.77 1.43 0.83
22.0°C 2.45 1.68 0.68 2.28 1.62 0.74 2.13 1.56 0.79 1.93 1.49 0.85
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.58 4.23 1.72 5.22 4.06 1.85 4.85 3.90 1.98 4.41 3.71 2.14
19.0°C 5.63 1.88
19.5°C 6.13 4.43 1.75 5.73 4.26 1.89 5.33 4.10 2.02 4.85 3.90 2.18
22.0°C 6.68 4.60 1.79 6.24 4.42 1.92 5.81 4.26 2.05 5.28 4.07 2.22
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.54 4.20 1.69 5.17 4.02 1.81 4.81 3.87 1.94 4.37 3.67 2.09
19.0°C 5.58 1.84
19.5°C 6.08 4.39 1.72 5.68 4.22 1.85 5.28 4.06 1.98 4.80 3.87 2.13
22.0°C 6.62 4.56 1.75 6.19 4.38 1.88 5.76 4.23 2.01 5.23 4.03 2.17
TC - Total Cooling (kW) Indoor 27°C/19°C
SHC - Sensible Heat Capacity (kW) Outdoor 35°C/24°C
IP - Input Power (kw)
68
CS-C9BKPG CU-2C14BKP5G / CS-C9BKPG CU-2C18BKP5G / CS-C9BKPG CU-3C20BKP5G / CS-C7BKPG CU-2C19BKP5G / CS-C12BKPG
