Operation manual
2
CU-5~10MX1SPP
Urban Multi air conditioner
4PW12337-1
15
TIMER ON/OFF BUTTON
Refer to page 4.
16
INSPECTION/TEST OPERATION BUTTON
This button is used only by qualified service persons for
maintenance purposes.
17
PROGRAMMING TIME BUTTON
Use this button for programming "START and/or STOP" time.
18
TEMPERATURE SETTING BUTTON
Use this button for SETTING TEMPERATURE.
19
FILTER SIGN RESET BUTTON
Refer to the indoor unit manual.
20
FAN SPEED CONTROL BUTTON
Press this button to select the fan speed, HIGH or LOW, of your
choice.
21
OPERATION MODE SELECTOR BUTTON
Press this button to select OPERATION MODE.
22
AIR FLOW DIRECTION ADJUST BUTTON
Refer to page 4.
23
OPERATION MODE/FAN SPEED
Not applicable.
24
FAN ONLY/AIR CONDITIONING SELECTOR SWITCH
Set the switch to
for fan only operation or to for heating
or cooling operation.
25
COOL/HEAT CHANGEOVER SWITCH
Set the switch to
for cooling or to for heating operation.
W
ARNING
Never do the following
■
Never let the indoor unit or the remote controller get wet.
It may cause an electric shock or a fire.
■
Never use flammable spray such as hair spray, lacquer or paint
near the unit.
It may cause a fire.
■
Never touch the air outlet or the horizontal blades while the
swing flap is in operation.
Fingers may become caught or the unit may break down.
■
Never replace a fuse with that of wrong ampere ratings or other
wires when a fuse blows out.
Use of wire or copper wire may cause the unit to break down or
cause a fire.
■
Never put any objects into the air inlet or outlet.
Objects touching the fan at high operating speed can be
dangerous.
■
Never remove the fan guard of the outdoor unit.
A fan rotating at high speed without the fan guard is very
dangerous.
■
Never press the button of the remote controller with a hard,
pointed object.
The remote controller may be damaged.
■
Never pull or twist the electric wire of the remote controller.
It may cause the unit to malfunction.
■
Never inspect or service the unit by yourself.
Ask a qualified service person to perform this work.
■
To prevent refrigerant leak, contact your Panasonic dealer.
When the system is installed and run in a small room, it is
required to keep the concentration of the refrigerant, if by and
chance coming out, bellow the limit. Otherwise, oxygen in the
room may be affected, resulting in a serious accident.
O
PERATION
RANGE
Use the system in the following temperature and humidity ranges for
safe and effective operation.
O
PERATION
PROCEDURE
■
If a function that is not available is selected, the message NOT
AVAILABLE will appear.
■
Operation procedure varies according to the combination of
outdoor unit and remote controller. Read "What to do before
operation" on page 1.
■
To protect the unit, turn on the main power switch 6 hours before
operation.
■
If the main power supply is turned off during operation, operation
will restart automatically after the power turns back on again.
Cooling, heating, and fan only operation
(See figure 4 and figure 7.1)
■
Changeover cannot be made with a remote controller whose
display shows (changeover under control).
■
When the display (changeover under control) flashes,
refer to "Setting the master remote controller" on page 4.
■
The fan may keep on running for about 1 minute after the
heating operation stops.
■
The air flow rate may adjust itself depending on the room
temperature or the fan may stop immediately. This is not a
malfunction.
NOTE
■
In contrast to actual operating situations, the
display on figure 1 shows all possible indications.
■
If the filter sign lamp lights up, clean the air filter
as explained in the indoor unit manual. After
cleaning and reinstalling the air filter: press the
filter sign reset button on the remote controller.
The filter sign lamp on the display will go out.
CU-5~10MX1SPP COOLING HEATING
outdoor temperature -5~43°CDB -13.7~21°CDB
-15~15.5°CWB
indoor temperature 21~32°CDB 15~27°CDB
15.5~25°CWB
indoor humidity
≤
80%
(*)
(*) to avoid condensation and water dripping out the unit.
If the temperature or the humidity is beyond these conditions, safety
devices may work and the air conditioner may not operate.
