REF. NO. PART NAME & DESCRIPTION QTY. CS-F24DB4E5 CS-F28DB4E5
1 BASE PAN ASS’Y 1 CWD52K1099
←
←←
←
2 INNER POLYSTYRENE COMPLETE 1 CWG07C1045
←
←←
←
3 CABINET SIDE PLATE ASS’Y 1 CWE041112
←
←←
←
4 CABINET SIDE PLATE ASS’Y 1 CWE041113
←
←←
←
6 FAN MOTOR 1 EHDS50A40AC
←
←←
←
7 ANTI-VIBRATION BUSHING 3 CWH501065
←
←←
←
9 SCREW-FAN MOTOR 3 CWH7080300
←
←←
←
11 TURBO FAN 1 CWH03K1021
←
←←
←
12 NUT for TURBO FAN 1 CWH561042
←
←←
←
13 SP WASHER 1 XWA8
←
←←
←
14 WASHER 1 XWG8H22
←
←←
←
15 EVAPORATOR COMPLETE 1 CWB30C1514
←
←←
←
16 FLARE NUT (5/8”) 1 CWT251016
←
←←
←
17 HEATPROOF TUBE 1 CWG021035
←
←←
←
18 HEATPROOF TUBE 1 CWG021021
←
←←
←
19 FLARE NUT (3/8”) 1 CWT25087
←
←←
←
21 PIPE COVER 1 CWD93C1047
←
←←
←
22 SENSOR-EVAPORATOR 1 CWA50C2216
←
←←
←
23 HOLDER SENSOR 1 CWH321044
←
←←
←
24 EVAPORATOR SUPPORTER 1 CWD911404A
←
←←
←
25 TUBE ASS’Y (CAPIL. TUBE) 1 CWT07K1183
←
←←
←
26 DRAIN PUMP COMPLETE 1 CWB53C1014
←
←←
←
27 PANEL DRAIN PUMP ASS’Y 1 CWD93K1007
←
←←
←
28 DRAIN PUMP 1 CWB532043
←
←←
←
29 ANTI-VIBRATION BUSHING 3 CWH501080
←
←←
←
30 FLOAT SWITCH-DRAIN PUMP 1 CWA121215
←
←←
←
31 FLEXIBLE PIPE 1 CWH851030
←
←←
←
32 DRAIN NOZZLE 1 CWH411013
←
←←
←
33 DRAIN HOSE HEAT INSULATION 1 CWG101025
←
←←
←
35 DRAIN PAN-COMPLETE 1 CWH40C1033
←
←←
←
36 DRAIN PLUG 1 CWB821008
←
←←
←
37 AIR GUIDER BLOWER WHEEL 1 CWD321057
←
←←
←
38 CONTROL BOARD CASING 1 CWH10K1047
←
←←
←
39 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1689 CWA73C1690
40 SPACER 6 CWH541026
←
←←
←
41 TRANSFORMER 1 G0A203H00001
←
←←
←
42 TERMINAL BOARD - (2 PIN) 1 CWA28K1112
←
←←
←
43 TERMINAL BOARD - (3 PIN) 1 CWA28K1076
←
←←
←
44 LEADWIRE-AIR TEMP. SENSOR 1 CWA67C5139
←
←←
←
47 CONTROL BOARD COVER 1 CWH13C1097
←
←←
←
48 ACCESSORY COMPLETE 1 CWH82C1270
←
←←
←
48A HEATPROOF TUBE 1 CWG021025
←
←←
←
49 WIRED REMOTE CONTROL COMPLETE (ACCESSORY) 1 CWG50C2604
←
←←
←
50 WIRED REMOTE CONTROL COMPLETE 1 CWA75C2586
←
←←
←
51 WIRELESS REMOTE CONTROL COMPLETE 1 CWA75C2588
←
←←
←
52 RAY RECEIVER COMPLETE 1 CWD91C0038
←
←←
←
100 CORD HOLDER 1 CWD741020
←
←←
←
OPERATING INSTRUCTION 1 CWF564508
←
←←
←
INSTALLATION INSTRUCTION 1 CWF612614
←
←←
←
OPERATING INSTRUCTION (ENG., DEU., NED.) 1 CWF564397
←
←←
←
OPERATING INSTRUCTION (ITA., GRE., FRA.) 1 CWF564398
←
←←
←
OPERATING INSTRUCTION 1 CWF564399
←
←←
←
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
89
CS-F24DB4E5 CU-L24DBE5 / CS-F28DB4E5 CU-L28DBE5
