NO. PART DESCRIPTION QTY. CU-L24DBE5 CU-L28DBE5
1 BASE PAN ASS’Y 1 CWD52K1098
←
←←
←
2 COMPRESSOR 1 5KD240XAA21
←
←←
←
3 ANTI-VIBRATION BUSHING 3 CWH50055
←
←←
←
4 NUT FOR COMP. MOUNT. 3 CWH4582065
←
←←
←
4a PACKING 1 CWB811017
←
←←
←
5 CRANKCASE HEATER 1 CWA341012
←
←←
←
6 CONDENSER COMPLETE 1 CWB32C1464
←
←←
←
7 TUBE ASS’Y(PRESSURE SWITCH) 1 CWT023311
←
←←
←
8 DISCHARGE MUFFLER 1 CWB121013
←
←←
←
9 HIGH PRESSURE SWITCH 1 CWA101007
←
←←
←
10 3-WAYS VALVE (GAS) 1 CWB011251
←
←←
←
11 4-WAYS VALVE 1 CWB001026
←
←←
←
12 3-WAYS VALVE (LIQUID) 1 CWB011252
←
←←
←
13 STRAINER 2 CWB111032
←
←←
←
15 PIPE HOLDER RUBBER 3 CWG251021
←
←←
←
17 HOLDER-SERVICE VALVE 1 CWD911425
←
←←
←
19 ACCUMULATOR ASS’Y 1 CWB131025A
←
←←
←
20 SOUND PROOF MATERIAL-COMP 1 CWG302245
←
←←
←
21 SOUND PROOF MATERIAL 1 CWG302246
←
←←
←
22 SOUND-PROOF BOARD ASS’Y 1 CWH151075
←
←←
←
23 V-COIL COMPLETE 1 CWA43C2169
←
←←
←
24 V-COIL COMPLETE (4 WAY VALVE) 1 CWA43C2128
←
←←
←
25 PIPE SENSOR (DISCHARGE) 1 CWA50C2213
←
←←
←
26 PIPE SENSOR (COIL) 1 CWA50C2214
←
←←
←
27 PIPING SENSOR 1 CWA50C2215
←
←←
←
28 CABINET REAR PLATE 1 CWE02C1013
←
←←
←
29 CONTROL BOARD ASS’Y 1 CWH10K1046
←
←←
←
31 TERMINAL BOARD ASS’Y 1 CWA28K1085
←
←←
←
32 TERMINAL BOARD ASS’Y 1 CWA28K1076
←
←←
←
33 CAPACITOR-FAN MOTOR (3/460) 1 DS461305QP-A
←
←←
←
34 ELECTRONIC CONTROLLER (P. SUPPLY) 1 CWA743402
←
←←
←
36 ELECTRONIC CONTROLLER (DISPLAY) 1 CWA743403
←
←←
←
38 ELECTRONIC CONTROLLER (NOISE FILTER) 1 CWA743480
←
←←
←
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1680R CWA73C1681R
46 REACTOR 2 CWA421066
←
←←
←
47 PARTICULAR PLATE COVER ASS’Y 1 CWD90K1023
←
←←
←
48 TERMINAL COVER 1 CWH171035
←
←←
←
49 NUT FOR TERMINAL COVER 1 CWH7080300
←
←←
←
50 BRACKET FAN MOTOR 1 CWD54K1010
←
←←
←
50a SCREW-BRACKET FAN MOTOR 2 CWH551040
←
←←
←
54 FAN MOTOR 1 CWA951363
←
←←
←
54a SCREW-FAN MOTOR 4 CWH551040
←
←←
←
55 PROPELLER FAN 1 CWH001019
←
←←
←
56 NUT for PROPELLER FAN 1 CWH561038
←
←←
←
57 CABINET FRONT PLATE 1 CWE061088A
←
←←
←
58 DISCHARGE GRILLE 1 CWE201073
←
←←
←
59 CABINET SIDE PLATE 1 CWE04K1019A
←
←←
←
60 WIRE NET 1 CWD041060A
←
←←
←
61 CABINET TOP PLATE COMPLETE 1 CWE03C1021
←
←←
←
62 ACCESSORY COMPLETE 1 CWH82C1105
←
←←
←
63 BAG-COMPLETE (L-TUBE) 1 CWG87C2030
←
←←
←
64 PIPE COVER (FRONT) 1 CWD601074A
←
←←
←
65 PIPE COVER (BACK) 1 CWD601075A
←
←←
←
66 CABINET FRONT PLATE COMPLETE 1 CWE06C1086
←
←←
←
67 HANDLE 2 CWE161008
←
←←
←
68 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1184
←
←←
←
100 LEADWIRE-COMPRESSOR 1 CWA67C5138
←
←←
←
101 SPRING FOR SENSOR 4 CWH711010
←
←←
←
102 4-WAYS VALVE COMPLETE 1 CWB00C1017
←
←←
←
103 CONDENSER SIDE PLATE 1 CWD932423
←
←←
←
104 TUBE ASS’Y(VALVE+STRAINER) 1 CWT023313
←
←←
←
INSTALLATION INSTRUCTION 1 CWF612612
←
←←
←
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
95
CS-F24DB4E5 CU-L24DBE5 / CS-F28DB4E5 CU-L28DBE5
