46
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CS-PC12JKF REMARK
1 CHASSY COMPLETE 1 CWD50C1599
2 FAN MOTOR 1 CWA921413 O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1076
4 BEARING ASS’Y 1 CWH64K007
5 SCREW - CROSS FLOW FAN 1 CWH551146
6 EVAPORATOR CO. 1 CWB30C2850
7 FLARE NUT (LIQUID) 1 CWT251026
8 FLARE NUT (GAS) 1 CWT25007
9 CLIP FOR SENSOR 1 CWH32143
10 DISCHARGE GRILLE COMPLETE 1 CWE20C3009
11 VERTICAL VANE 11 CWE241287
12 CONNECTING BAR 1 CWE261152
13 CONNECTING BAR 1 CWE261153
14 CONNECTING BAR 1 CWE261154
15 CONNECTING BAR 1 CWE261155
16 FULCRUM 1 CWH621102
17 AIR SWING MOTOR DC SINGLE 12V 300OHM 1 CWA981240 O
18 CAP - DRAIN TRAY 1 CWH521096
19 HORIZONTAL VANE COMPLETE 1 CWE24C1268
20 BACK COVER CHASSIS 1 CWD933019
21 CONTROL BOARD CASING 1 CWH102370
22 TERMINAL BOARD COMPLETE 1 CWA28C2388 O
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C3465 O
24 ELECTRONIC CONTROLLER - POWER 1 CWA745284 O
25 ELECTRONIC CONTROLLER - INDICATOR & RECEIVER 1 CWA745300 O
26 INDICATOR HOLDER 1 CWD933021
27 SENSOR COMPLETE 1 CWA50C2401 O
28 CONTROL BOARD FRONT COVER 1 CWH13C1183
29 CONTROL BOARD TOP COVER 1 CWH131350
31 REMOTE CONTROL COMPLETE 1 CWA75C3297 O
32 FRONT GRILLE COMPLETE 1 CWE11C4099 O
33 INTAKE GRILLE COMPLETE 1 CWE22C1508 O
34 GRILLE DOOR COMPLETE 1 CWE14C1029
35 AIR FILTER 2 CWD001279
36 SCREW - FRONT GRILLE 2 XTT4+16CFJ
37 CAP - FRONT GRILLE 2 CWH521194
38 DRAIN HOSE 1 CWH851063
39 INSTALLATION PLATE 1 CWH361097
40 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
41 INSTALLATION INSTRUCTION 1 CWF613773
42 INSTALLATION INSTRUCTION 1 CWF613687
45 OPERATING INSTRUCTION 1 CWF566364
