Panasonic CU-PC24MKF - Page 81

81
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CS-PC18MKF CS-PC24MKF REMARK
1 CHASSIS COMPLETE 1 CWD50C1654
←
2 FAN MOTOR 1 ARW7628AC ARW7627AC O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1077
←
4 BEARING ASS’Y 1 CWH64K007 ←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ←
7 EVAPORATOR 1 CWB30C3126 CWB30C3125
8 FLARE NUT (LIQUID) 1 CWT251026
←
9 FLARE NUT (GAS) 1 CWT251062 CWT251036
12 HOLDER SENSOR 1 CWH32143
←
13 CONTROL BOARD CASING 1 CWH102370 ←
14 TERMINAL BOARD COMPLETE 1 CWA28C2361 CWA28C2362 O
16 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5233 CWA73C5232 O
19 ELECTRONIC CONTROLLER - INDICATOR 1 CWA746317
← O
20 ELECTRONIC CONTROLLER - RECEIVER 1 CWA745288
← O
21 SENSOR COMPLETE 1 CWA50C2401 CWA50C2782 O
22 CONTROL BOARD TOP COVER 1 CWH131350
←
24 INDICATOR HOLDER 1 CWD933021 ←
26 CONTROL BOARD FRONT COVER 1 CWH13C1183 ←
27 DISCHARGE GRILLE COMPLETE 1 CWE20C3163 ←
28 FULCRUM 2 CWH621103 ←
29 VERTICAL VANE 13 CWE241355 ←
30 CONNECTING BAR 1 CWE261230 ←
31 CONNECTING BAR 1 CWE261231 ←
32 CONNECTING BAR 1 CWE261232 ←
33 CONNECTING BAR 1 CWE261233 ←
34 CONNECTING BAR 1 CWE261234 ←
37 A.S.MOTOR, DC SINGLE 12V 300OHM 1 CWA981241 ← O
39 CAP - DRAIN TRAY 1 CWH521096
←
40 HORIZONTAL VANE 1 CWE24C1295 ←
41 BACK COVER CHASSIS 1 CWD933031 ←
42 REMOTE CONTROL COMPLETE 1 CWA75C3712 ← O
43 FRONT GRILLE COMPLETE 1 CWE11C4801 CWE11C4802 O
44 INTAKE GRILLE COMPLETE 1 CWE22C1512
← O
45 GRILLE DOOR 1 CWE14C1029
←
46 AIR FILTER 2 CWD001283 ←
47 SCREW - FRONT GRILLE 4 XTT4+16CFJ ←
48 CAP - FRONT GRILLE 3 CWH521194 ←
49 DRAIN HOSE 1 CWH851173 ←
50 INSTALLATION PLATE 1 CWH361098 ←
51 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
52 OPERATING INSTRUCTION 1 CWF567879 ←
53 INSTALLATION INSTRUCTION 1 CWF614761 ←
54 INSTALLATION INSTRUCTION 1 CWF614762 ←
55 COVER FOR RECEIVER (BOTTOM) 1 CWD933209 ←
56 COVER FOR RECEIVER (UPPER) 1 CWD933022 ←
57 SENSOR COMPLETE (ECO) 1 CWA50C2709 ←
58 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA745791 ←
59 ELECTRONIC CONTROLLER (COMPARATOR) 1 CWA745790 ←
60 LEAD WIRE - PCB ECO 1 CWA67C8484 ←
61 COVER FOR PCB ECO (BOTTOM) 1 CWD933193 ←
62 COVER FOR PCB ECO (UPPER) 1 CWD933192 ←
