Panasonic CU-S24PKH - Page 158

158
CS-S10PKH CS-S13PKH CS-S15PKH
SAFETY REF. NO. PART NAME & DESCRIPTION QTY.
Malaysia only
REMARK
1 CHASSIS COMPLETE 1 CWD50C1653 ← ←
2 FAN MOTOR 1 ARW7628AC CWA921441 ARW7628AC O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1149 ← ←
4 BEARING ASSY 1 CWH64K007 ← ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ←
6 GENERATOR COMPLETE 1 CWH94C0043 ← ←
7 EVAPORATOR 1 CWB30C4401 CWB30C4267 CWB30C4374
8 FLARE NUT (LIQUID) 1 CWT251030 ← ←
9 FLARE NUT (GAS) 1 CWT251031 CWT251032 ←
10 CLIP FOR SENSOR 1 CWH711019 ← ←
11 CONTROL BOARD CASING 1 CWH102449 ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2405 CWA28C2381 ← O
13 ELECTRONIC CONTROLLER - MAIN 1 CWA73C7275 CWA73C7277 CWA73C7279 O
14 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000002 ← ← O
15 ELECTRONIC CONTROLLER - INDICATOR 1 CWA746634 ← ← O
16 SENSOR COMPLETE 1 CWA50C2401 ← ← O
17 SENSOR COMPLETE (ECO) 1 CWA50C2809 ← ← O
18
ELECTRONIC CONTROLLER (ECO
SENSOR)
1 CWA745791 ← ← O
19
ELECTRONIC CONTROLLER (ECO
SENSOR)
1 CWA746206 ← ← O
20
ELECTRONIC
CONTROLLER(COMPARATOR)
1 CWA746653 ← ← O
21 LEAD WIRE - PCB ECO 1 CWA67C9785 ← ←
22 CONTROL BOARD CASING FOR PCB ECO 1 CWD933407 ← ←
23 CONTROL BOARD TOP COVER 1 CWH131467 ← ←
24 INDICATOR HOLDER 1 CWD933406 ← ←
25 CONTROL BOARD FRONT COVER CO. 1 CWH13C1247 ← ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3235 ← ←
27 BACK COVER CHASSIS 1 CWD933233 ← ←
28 FULCRUM 1 CWH621131 ← ←
29 VERTICAL VANE 8 CWE241374 ← ←
30 CONNECTING BAR (RIGHT) 1 CWE261250 ← ←
31 CONNECTING BAR (LEFT) 1 CWE261256 ← ←
32 AIR SWING MOTOR 1 CWA98K1016 ← ← O
33 AIR SWING MOTOR 1 CWA981264 ← ← O
34 CAP - DRAIN TRAY 1 CWH521259 ← ←
35 HORIZONTAL VANE COMPLETE 1 CWE24C1385 ← ←
36 REMOTE CONTROL COMPLETE 1 CWA75C4185 ← ← O
37 FRONT GRILLE COMPLETE 1 CWE11C5053 ← ← O
38 INTAKE GRILLE COMPLETE 1 CWE22C1723 ← ← O
39 GRILLE DOOR COMPLETE 1 CWE14C1090 ← ←
40 AIR FILTER 2 CWD001279 ← ←
41 SCREW - FRONT GRILLE 2 XTT4+16CFJ ← ←
42 CAP - FRONT GRILLE 2 CWH521227 ← ←
43 DRAIN HOSE 1 CWH851174 ← ←
44 INSTALLATION PLATE 1 CWH361134 ← ←
45 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ← ←
46 OPERATING INSTRUCTION 1 CWF568827 ← ←
47 INSTALLATION INSTRUCTION 1 CWF615577 ← ←
48 INSTALLATION INSTRUCTION 1 CWF615578 ← ←
