Model Piping side Torque
CS-SA12CKP
CU-SA12CKP5
Gas side 1/2" 55N.n
For the left side piping
1. Route the indoor tubing with the drain hose to the hole.
•
• •
•
Pull out the drain hose.
•
• •
•
Exchange the hose and cap.
2. Insert the piping and connecting cable to indoor side
through the hole.
3. Insert the connecting cable into the connecting cable
•
• •
•
Do not connect the cable to the indoor unit.
•
• •
•
Make a small loop with the cable for easy con nection.
