1-203

Simultaneous (Twin) -Type

1-1. Unit Speciﬁ cations

PEY1

6. 4-Way Cassette 60×60 Type S-36PY2E5A×2 / U-71PEY1E5

INDOOR MODEL S-36PY2E5A ×2

PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×2

OUTDOOR MODEL U-71PEY1E5

Branch pipe MODEL CZ-P155BK1

PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102

POWER SUPPLY

ø, Hz 1ø 50Hz 1ø 50Hz

V 220 230 240 220 230 240 Min Max

CAPACITY

kW 7.1 7.1 7.1 2.0 7.7

BTU/h 24200 24200 24200 6800 26300

CURRENT A 0.30 × 2 11.0 10.5 10.0 - -

INPUT POWER

W 40 × 2 2.170k 2.170k 2.170k - -

TOTAL W - 2.250k 2.250k 2.250k 325 2.900k

ANNUAL CONSUMPTION

TOTAL kWh

4----1125---

EER/EER CLASS

TOTAL(W/W)

5/("A"~"G")

- - - 3.15 3.15/B 3.15 6.15 2.66

Erp

Pdsign kW ----7.1-

SEER (W/W) ----5.7-

Annual consumption

kWh----436-

Class ----A+-

POWER FACTOR % - - - 90 90 90

NOISE INDOOR

(H/M/L)

dB-A 36/32/26(31)*7

Power Level dB 51/47/41(46)*7

NOISE OUTDOOR

(H/L)

dB-A 50/-

Power Level dB 70/-

CAPACITY

kW 7.1 7.1 7.1 1.8 8.1

BTU/h 24200 24200 24200 6100 27600

CURRENT A 0.30 × 2 9.70 9.25 8.80 - -

INPUT POWER

W 35 × 2 1.920k 1.920k 1.920k - -

TOTAL W - 1.990k 1.990k 1.990k 275 2.700k

COP/COP CLASS

TOTAL(W/W)

5/("A"~"G")

- - - 3.56 3.56/B 3.56 6.55 3.00

Erp

Pdsign kW ----5.5-

Tbivalen °C -----6-

SCOP (W/W) ----3.8-

Annual consumption

kWh----2026 -

Class ----A-

POWER FACTOR % - - - 90 90 91

NOISE INDOOR

(H/M/L)

dB-A 36/32/26(31)*7 -

Power Level dB 51/47/41(46)*7 -

NOISE OUTDOOR

(H/L)

dB-A - 52/-

Power Level dB - 70/-

EXTRA LOW TEMP

Total CAPACITY(kW)/INPUT POWER(W)/COP

MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 2 18.0/3.64k 18.0/3.81k 18.0/3.97k

STARTING CURRENT(A)/COMP OUTPUT(W) - - - 11.0/2.2k 10.5/2.2k 10.0/2.2k

NETWORK IMPEDANCE (ΩMAX.) - -

FM OUTPUT (W) 40 × 2 90

MOISTURE REMOVAL VOLUME L/h(Pt/h) 4.2 (2.1×2) (8.8) -

I/D AIR

FLOW

COOL m

/min (ft

/min)

9.7×2/8.0×2/6.0×2*7 (343)×2/(283)×2/(212)×2

HEAT m

/min (ft

/min)

9.9×2/8.2×2/6.0×2*7 (350)×2/(290)×2/(212)×2

O/D AIR

FLOW

COOL m

/min (ft

/min) 39 (1377)

HEAT m

/min (ft

/min) 39 (1377)

REFRIGERANT TYPE, AMOUNT

(oz) R410A 1.70k (60.0)

HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 569 (22-13/32)

WIDTH : W mm(inch) 575<583> (22-21/32) 790 (31-7/64)

DEPTH : D mm(inch) 575<583> (22-21/32) 285 (11-7/32)

Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625

HEIGHT : H mm 345 (13-19/32) 645

WIDTH : W mm 691 (27-7/32) 921

DEPTH : D mm 691 (27-7/32) 386

MASS

(NET) k

(lb) 18 (40) 42 (93)

(GROSS) k

(lb) 23 (51) 46 (101)

Panel : (NET) k

(lb) 2.4 (5.3)

LAYERS LIMIT (actually) 11 (12) 4 (5)

Operation

Condition

Cool (DBT) 18°C ~ 32°C -10°C ~ 43°C

Heat (DBT) 16°C ~ 30°C -15°C ~ 24°C

PIPE DIAMETER mm (inch)

(Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)

CONNECT METHOD, STD LENGTH m (ft)

ﬂ ared type, 5.0 (16.4) ﬂ ared type, 5.0 (16.4)

PIPE LENGTH RANGE m (ft)

5 ~ 50 (16.4 ~ 164.0)

I/D&O/D HEIGHT DIFFERENCE m (ft)

15(OD located lower)/30(OD located higher) (49.2/98.4)

ADD GAS AMOUNT

/m (oz/ft)

40 (0.430)

PIPE LENGTH FOR ADDITIONAL GAS m (ft)

20 (65.6)

*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m

/min.) shall be multiplied by 16.7 and rounded down the decimal point.

*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7

°C

dry bulb and -8

°C

wet-bulb temperatures with rated voltage 230V

shall be used.

*3: Network Impedance shall be applicable for EUROPE and CHINA models.

*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.

*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.

*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche

data indicates in an attached sheet.

*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are

7.6 (m

/min).
