Panasonic CZ-KPY3A series Technical Data & Service Manual

1
1-424
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 46°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-50PY2E5A
U-50PE1E5
220V
230V
240V
50Hz
1 phase
23
16 5.9 4.1 1.97 5.6 3.9 2.14 5.2 3.7 2.35 5.0 3.6 2.61 3.9 3.1 1.71
19 6.4 3.3 2.05 6.0 3.1 2.23 5.6 2.9 2.45 5.4 2.8 2.72 4.2 2.3 1.79
22 7.0 2.5 2.13 6.5 2.3 2.31 6.1 2.1 2.55 5.9 2.0 2.83 4.6 1.6 1.86
25
16 5.9 4.5 1.97 5.6 4.4 2.14 5.2 4.2 2.35 5.0 4.1 2.61 3.9 3.6 1.71
19 6.4 3.7 2.05 6.0 3.5 2.23 5.6 3.4 2.45 5.4 3.3 2.72 4.2 2.8 1.79
22 7.0 2.9 2.13 6.5 2.7 2.31 6.1 2.6 2.55 5.9 2.5 2.83 4.6 2.0 1.86
27
16 5.9 5.0 1.97 5.6 4.9 2.14 5.2 4.7 2.35 5.0 4.6 2.61 3.9 3.9 1.71
19 6.4 4.2 2.05 6.0 4.0 2.23 5.6 3.8 2.45 5.4 3.8 2.72 4.2 3.3 1.79
22 7.0 3.4 2.13 6.5 3.2 2.31 6.1 3.1 2.55 5.9 3.0 2.83 4.6 2.5 1.86
29
16 5.9 5.5 1.97 5.6 5.4 2.14 5.2 5.2 2.35 5.0 5.0 2.61 3.9 3.9 1.71
19 6.4 4.7 2.05 6.0 4.5 2.23 5.6 4.3 2.45 5.4 4.3 2.72 4.2 3.7 1.79
22 7.0 3.9 2.13 6.5 3.7 2.31 6.1 3.5 2.55 5.9 3.5 2.83 4.6 3.0 1.86
32
16 5.9 5.5 1.97 5.6 5.4 2.14 5.2 5.2 2.35 5.0 5.0 2.61 3.9 3.9 1.71
19 6.4 4.7 2.05 6.0 4.5 2.23 5.6 4.3 2.45 5.4 4.3 2.72 4.2 3.7 1.79
22 7.0 3.9 2.13 6.5 3.7 2.31 6.1 3.5 2.55 5.9 3.5 2.83 4.6 3.0 1.86
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Single Unit
4-Way Cassette 60×60 Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
