Specifications
Power Supply: AC 220k(1n10%) V to 240 k(1n10%) V,
50 k(1n10%) Hz
Power Consumption: 36 W
(Approx. 7 W in Normal standby mode/
Approx. 15 W in Quick start standby
mode/Approx. 4 W in power save mode)
∫DVD
Recording format DVD-RAM: DVD Video Recording format
DVD-R, DVD-RW: DVD-Video format
Video: MPEG2
Audio: Dolby Digital 2 CH
Optical pickup System with 1 lens, 2 integration units
(wavelength: 662 nm for DVD, 795 nm for CD)
Recording disc
DVD-RAM:
Ver. 2.0
Ver. 2.1/3k-SPEED DVD-RAM Revision 1.0
Ver. 2.2/5k-SPEED DVD-RAM Revision 2.0
DVD-R:
for General Ver. 2.0
for General Ver. 2.0/4k-SPEED DVD-R Revision 1.0
for General Ver. 2.x/8k-SPEED DVD-R Revision 3.0
DVD-RW:
Ver. 1.1
Ver. 1.1/2k-SPEED DVD-RW Revision 1.0
Ver. 1.2/4k-SPEED DVD-RW Revision 2.0
+R:
Ver. 1.0
Ver. 1.1
Ver. 1.2
Recording mode/recording time (with 4.7 GB disc)
XP: approx. 10 Mbps/approx. 60 min
SP: approx. 5 Mbps/approx. 120 min
LP: approx. 2.5 Mbps/approx. 240 min
EP: approx. 1.7/1.2 Mbps/approx. 360/480 min
Playable discs
DVD-RAM, DVD-R, DVD-RW, +R, +RW,
DVD-Video, DVD-Audio, Video CD, CD-Audio (CD-DA),
CD-R/CD-RW (MP3, JPEG, CD-DA, Video CD
formatted discs)
Region code 4
Video interface
Input °
1
AV1 Pin jack: Video: 1 Vp-p
AV2 Pin jack: Video: 1 Vp-p
SVideo: Y: 1 Vp-p, C: 0.286 Vp-p
AV3 Pin jack: Video: 1 Vp-p
SVideo: Y: 1 Vp-p, C: 0.286 Vp-p
Output °
2
DVD/VHS COMMON
Pin jack: Video: 1 Vp-p
DVD Pin jack: Video: 1 Vp-p
SVideo: Y: 1 Vp-p, C: 0.286 Vp-p
Component Video (Pin jack):
Y: 1 Vp-p, P
B: 0.7 Vp-p, PR: 0.7 Vp-p
Audio interface
Input °
3
AV1 Pin jack: Standard: 0.5 Vrms, Full scale: 2 Vrms at 1 kHz
AV2 Pin jack: Standard: 0.5 Vrms, Full scale: 2 Vrms at 1 kHz
AV3 Pin jack: Standard: 0.5 Vrms, Full scale: 2 Vrms at 1 kHz
Output
DVD/VHS COMMON
Pin jack °
4
: Standard: 0.5 Vrms, Full scale: 2 Vrms at 1 kHz
DVD Pin jack °
4
: Standard: 0.5 Vrms, Full scale: 2 Vrms at 1 kHz
Digital Audio (Optical terminal):
PCM, Dolby Digital, DTS
Video data
Horizontal resolution:
More than
XP: 500 lines SP: 500 lines
LP: 500 lines EP: 250 lines
Signal to Noise Ratio:
More than 45 dB
Frequency Response:
XP, SP: j1.5 dB n2 dB at 3 MHz (0 dB at 0.1 MHz)
LP, EP: j0.5 dB n3 dB at 2 MHz (0 dB at 0.1 MHz)
Audio data
Dynamic Range: Rec/PB: more than 90 dB
DVD-Video PB (with LPCM): more than 96 dB
CD PB: more than 96 dB
Frequency Response:
XP, SP, LP, EP (6H mode): 20 Hz to 20 kHz (0 dB
n3dB)
EP (8H mode): 20 Hz to 12 kHz (0 dB n3 dB)
Cross Talk: More than 60 dB at 1 kHz
LASER Specification
Class 1 LASER Product (Pickup)
Wave Length: 795 nm, 662 nm
Laser Power: No hazardous radiation is emitted with the safety
protection
∫VHS
Recording format VHS Video Cassette System Standard with FM audio
(PAL, NTSC°)
°NTSC recording from external source or DVD disc,
not from TV tuner.
Heads 4 helical scan heads for video
2 helical scan heads for FM audio
1 fixed head for Normal audio
Recording mode/recording time (with E-240 cassette)
PAL: SP: 23.39 mm/s
LP: 11.7 mm/s
EP: 7.8 mm/s
240 min
480 min
720 min
NTSC: SP: 33.35 mm/s
EP: 11.12 mm/s
168 min
505 min
Others FF/REW: approx. 60 s,
JET REW: approx. 43 s (with E-180 cassette)
Video interface
Input °
1
AV1 Pin jack: Video: 1 Vp-p
AV2 Pin jack: Video: 1 Vp-p
SVideo: Y: 1 Vp-p, C: 0.286 Vp-p
AV3 Pin jack: Video: 1 Vp-p
SVideo: Y: 1 Vp-p, C: 0.286 Vp-p
Output °
2
DVD/VHS COMMON
Pin jack: Video: 1 Vp-p
Audio interface
Input °
3
AV1 Pin jack: j6 dBV
AV2 Pin jack: j6 dBV
AV3 Pin jack: j6 dBV
Output °
4
DVD/VHS COMMON
Pin jack: j6 dBV
Video data
Horizontal resolution:
More than 240 lines
Signal to Noise Ratio:
More than
SP: 40 dB LP: 40 dB
EP: 38 dB
Frequency Response:
SP, LP: 0 dB n2 dB at 2 MHz (0 dB at 0.1 MHz)
EP: 0 dB n3 dB at 2 MHz (0 dB at 0.1 MHz)
Audio data
Dynamic Range: Hi-Fi: more than 90 dB
Frequency Response:
Hi-Fi: 20 Hz to 20 kHz (0 dB n3 dB)
Normal SP: 80 Hz to 8 kHz (j1 dB n5 dB)
Normal LP: 80 Hz to 5 kHz (0 dB n5 dB)
Normal EP: 80 Hz to 3 kHz (0 dB n5 dB)
Signal to Noise Ratio:
Hi-Fi: more than 65 dB
Normal SP: more than 43 dB
Normal EP: more than 41 dB
Cross Talk: More than 50 dB at 1 kHz (Hi-Fi)
Wow and Flutter: Hi-Fi: less than 0.005 Wrms
Normal SP: 0.2% max.
Normal EP: 0.4% max.
