Panasonic DMC-FT2EB - Page 63

DMC-FT2 / TS2 Series
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
74 VGQ0N02 REAR BARRIER SHEET 1
1 VYK3Q30 REAR ALMI CASE U 1 (-S) [PAVCSG] 77 VGQ0N11 REAR LENS CUSHION B 1
1 VYK3U37 REAR ALMI CASE U 1 (-A) [PAVCSG] 78 VGQ0N10 REAR LENS CUSHION A 1
1 VYK3U38 REAR ALMI CASE U 1 (-D) [PAVCSG] 79 VGQ0N03 PCB SPACER 1
1 VYK3U39 REAR ALMI CASE U 1 (-Y) [PAVCSG] 80 VGQ9405 WATER LABEL 1 [PAVCSG]
2 VMP9662 LENS PLATE 1
 3 VQL2D05 BATTERY DOOR CAUTION LABEL 1 EG,EB,EE,EF,EP,GC,GN,SG, B1 VHD2067 SCREW 1
P,PU,GH B2 VHD2067 SCREW 1
 3 VQL2D06 BATTERY DOOR CAUTION LABEL 1 PC B3 VHD2067 SCREW 1
3 VQL2D54 BATTERY DOOR CAUTION LABEL 1 GT B4 VHD2067 SCREW 1
3 VQL2D55 BATTERY DOOR CAUTION LABEL 1 GD B5 VHD2222 SCREW 1
4 VXW1116 LENS UNIT (W/CCD) 1 B6 VHD2222 SCREW 1
5 VYK4D91 REAR CASE U 1 B7 VHD2222 SCREW 1
6 VGQ0M09 CONDENSER BARRIER TAPE B 1 [PAVCSG] B8 VHD2222 SCREW 1
7 VMP9567 REAR FPC PLATE 1 B9 VHD2212 SCREW 1
8 VYK3Y46 LCD ASSY 1 B10 VHD2212 SCREW 1
9 VYK3H61 MODE DIAL U 1 B11 VHD2212 SCREW 1 [PAVCSG]
10 VEK0N46 FLASH U 1 [PAVCSG] B17 VHD1909 SCREW 1
12 VMP9328 MODE DIAL PIECE 1 B18 VHD1909 SCREW 1
13 VEP50056A REAR OPERATION P.C.B. 1 (RTL) E.S.D. B19 VHD1909 SCREW 1
14 VGQ0E07 MODE DIAL ARM 1 B20 VHD1909 SCREW 1
15 VGU0F60 REAR BUTTON DISPLAY 1 [PAVCSG] B21 VHD1909 SCREW 1
16 VGU0F62 REAR BUTTON CENTER 1 [PAVCSG] B22 VHD1909 SCREW 1
17 VGU0F63 REAR BUTTON CROSS 1 [PAVCSG] B23 VHD1909 SCREW 1
18 VGU0F64 REAR BUTTON PLAY 1 [PAVCSG] B24 VHD1886 SCREW 1
19 VGU0F65 REAR BUTTON REC 1 [PAVCSG] B25 VHD1694 SCREW 1
20 VGU0F61 REAR BUTTON Q.MENU 1 [PAVCSG] B26 VHD2078 SCREW 1
22 VYK4E71 FRONT CASE U 1 FT2(-S) B27 VHD2078 SCREW 1
22 VYK4E74 FRONT CASE U 1 FT2(-A) B28 XQN16+BJ4FN SCREW 1
22 VYK4E72 FRONT CASE U 1 FT2(-D) B29 VHD2212 SCREW 1 [PAVCSG]
22 VYK4E73 FRONT CASE U 1 FT2(-Y) B30 VHD2212 SCREW 1 [PAVCSG]
22 VYK4E91 FRONT CASE U 1 TS2(-S: EXCEPT:TS2P) B31 VHD2213 SCREW 1 [PAVCSG]
22 VYK4E94 FRONT CASE U 1 TS2(-A : EXCEPT:TS2P) B34 VHD2215 SCREW 1
22 VYK4E92 FRONT CASE U 1 TS2(-D: EXCEPT:TS2P) B35 VHD2215 SCREW 1
22 VYK4E93 FRONT CASE U 1 TS2(-Y: EXCEPT:TS2P) B36 VHD1909 SCREW 1
22 VYK4E75 FRONT CASE U 1 TS2P-S B37 VHD1909 SCREW 1
22 VYK4E78 FRONT CASE U 1 TS2P-A B38 VHD1909 SCREW 1
22 VYK4E76 FRONT CASE U 1 TS2P-D B39 VHD1909 SCREW 1
22 VYK4E77 FRONT CASE U 1 TS2P-Y B40 VHD1909 SCREW 1
22-2 VMP9570 JACK DOOR PLATE 1 [PAVCSG] B41 VHD1909 SCREW 1
22-3 VMB4227-A DOOR KNOB SPRING 1 [PAVCSG] B42 XQN16+BJ4FN SCREW 1
22-4 VGU0F68 JACK DOOR KNOB 1 [PAVCSG] B43 XQN16+BJ4FN SCREW 1
22-5 VGQ0C31-A BATT DOOR LOCK LABEL 1 [PAVCSG] B44 XQN16+BJ4FN SCREW 1
22-6 VGQ0C31-A BATT DOOR LOCK LABEL 1 [PAVCSG] B45 XQN16+BJ6FN SCREW 1
22-7 VGQ0K09 JACK DOOR LOCK LEVER 1 [PAVCSG] B46 XQN16+BJ4FN SCREW 1
22-8 VMB4346 JACK DOOR LEVER SPRING 1 [PAVCSG] B47 VHD2074 SCREW 1
22-13 VMB4227-A DOOR KNOB SPRING 1 [PAVCSG] B48 VHD2214 SCREW 1
22-14 VGU0F67 BATT DOOR KNOB 1 [PAVCSG] B50 XQN16+BJ4FN SCREW 1
22-15 VGQ0C31-A BATT DOOR LOCK LABEL 1 [PAVCSG] B51 XQN16+BJ4FN SCREW 1 [PAVCSG]
22-16 VGQ0C31-A BATT DOOR LOCK LABEL 1 [PAVCSG] B53 VHD2078 SCREW 1
22-17 VMB4345 BATT DOOR LEVER SPRING 1 [PAVCSG]
22-18 VGQ0K08 BATT DOOR LOCK LEVER 1 [PAVCSG]
22-19 VKF4647 BATT DOOR 1 (-S) [PAVCSG]
22-19 VKF4697 BATT DOOR 1 (-A) [PAVCSG] P VUMG1918 PACKING KIT 1
22-19 VKF4695 BATT DOOR 1 (-D) [PAVCSG] P-1 ------- JACK DOOR PACKING 1 (Included in VUMG1918)
22-19 VKF4696 BATT DOOR 1 (-Y) [PAVCSG] P-2 ------- BATT DOOR PACKING 1 (Included in VUMG1918)
22-20 VQL2F13 BATTERY LABEL 1 P-3 ------- CASE O-RING 1 (Included in VUMG1918)
24 VEP56096B MAIN P.C.B. 1 EG,EB,EF,EP (RTL) E.S.D. P-4 ------- MODE DIAL O-RING 1 (Included in VUMG1918)
24 VEP56096A MAIN P.C.B. 1 EE,GC,GN,SG,P,PC,PU,GH, P-5 ------- REAR BUTTON PACKING 1 (Included in VUMG1918)
GT,GD (RTL) E.S.D.
30 VWJ2131 FPC 1
31 VGQ0J97 BATT FRAME 1 [PAVCSG]
33 VGQ0J98 BATT DETECT LEVER 1 [PAVCSG]
34 VGU0F66 BATT LOCK KNOB 1 [PAVCSG]
35 VMB4340 BATT OUT SPRING 1 [PAVCSG]
36 VMB4226-A BATT LOCK SPRING 1 [PAVCSG]
37 VMB4240-A BATT DETECT SPRING 1 [PAVCSG]
38 VMC2119 FRONT EARTH PLATE C 1 [PAVCSG]
39 VMP9568 BATT LOCK PLATE 1 [PAVCSG]
41 VMC2113 FL EARTH PLATE 1 [PAVCSG]
42 VEP58105A FLASH P.C.B. 1 (RTL) E.S.D.[PAVCSG]
45 VGQ0M64 STROBE BATTERY TAPE 1 [PAVCSG]
 64 ML-421S/ZTK BUTTON BATTERY 1 [ENERGY]㧔B6402㧕
65 VEK0Q54 FLASH CHRG CAPA. U 1 (C8006)
71 VGQ0N12 LENS CUSHION 1
72 VGQ0M54 EMC DPR SHEET A 1
73 VGQ0N04 EMC DPR SHEET B 1
