Getting started
VQT3C15
9
1 Turn the unit on and off (> 12)
2 Switch the media to playback (> 14)
3 Basic operations for playback (> 14–15)
4 Use according to the instructions on the screen
5 Show Top menu/Direct Navigator (> 14)
6 Selection/OK, Frame-by-frame
7 Show the sub menu
8 Select title numbers, etc./Enter numbers
9 Cancel the values that were entered
10 Mute the sound
Press again to clear
11 Adjust the volume (> 14)
12 Exit the menu screen
13 Show FUNCTION MENU (> 12)
14 Show Pop-up menu (> 14)
15 Select audio (> 16)
16 Return to previous screen
17 Show on-screen menu (> 24)
18 Show status messages (> 16)
19 Turn the unit off automatically (> 12)
20 Change the screen settings (> 13)
21 Change the setup of this unit (> 26)
∫ Insert the button-type battery (supplied)
1 Pull out the holder.
2 Insert the battery and return the holder.
≥ Keep the button-type battery out of reach of children to
prevent swallowing.
∫ Range of use
The distance and angles are approximate.
Remote control
ン
ヨ
ャ
ヺ
ヷヰロ
ビ
ピ
ヒ
フ
ブ
プ
ヘ
ベ
パ
ペ
1
3
6
7
5
4
8
9
2
17
12
19
21
20
11
10
13
14
15
16
18
≥ To select: Press up, down, left, or right ([3, 4, 2, 1])
≥ To enter: Press [OK]
≥ Frame forward / Frame backward:
(While paused) press left or right ([2;][;1])
Bottom
Pull out while pressing here
_
facing up
Lithium battery: CR2025
Remote control
signal sensor
Within 30 degrees angle
either left or right
Within 20 degrees
angle either up or
down
Remote control transmitter
Within 7 m (23 ft.) in front
DMP-B200P&PC-VQT3C15_eng.book 9 ページ ２０１０年１２月２２日 水曜日 午後６時２分
