Panasonic DMR-ES30VS

Reference
75
VQT0N92
Note
Mass and dimensions shown are approximate.
Specifications are subject to change without notice.
Specifications
Power Supply: AC 120k(1 ±10%) V, 50/60 Hz ±10%
Power Consumption: 31 W
(Approx. 10 W in Quick start standby
mode/Approx. 9 W in power save mode)
(Approx. 4 W in Normal standby mode/
Approx. 2 W in power save mode)
∫DVD
Recording format DVD-RAM: DVD Video Recording format
DVD-R, DVD-RW: DVD-Video format
Video: MPEG2
Audio: Dolby Digital 2 CH
Optical pickup System with 1 lens, 2 integration units
(wavelength: 662 nm for DVD, 795 nm for CD)
Recording disc
DVD-RAM: Ver. 2.0
Ver. 2.1/3k-SPEED DVD-RAM Revision 1.0
Ver. 2.2/5k-SPEED DVD-RAM Revision 2.0
DVD-R: for General Ver. 2.0
for General Ver. 2.0/4k-SPEED DVD-R Revision 1.0
for General Ver. 2.x/8k-SPEED DVD-R Revision 3.0
DVD-RW: Ver. 1.1
Ver. 1.1/2k-SPEED DVD-RW Revision 1.0
Ver. 1.2/4k-SPEED DVD-RW Revision 2.0
+R: Ver. 1.0
Ver. 1.1
Ver. 1.2
Recording mode/
recording time
XP: approx. 10 Mbps/approx. 60 min
SP: approx. 5 Mbps/approx. 120 min
LP: approx. 2.5 Mbps/approx. 240 min
EP: approx. 1.7/1.2 Mbps/approx. 360/480 min
(with 4.7 GB disc)
Playable discs
DVD-RAM, DVD-R, DVD-RW, +R, +RW,
DVD-Video, DVD-Audio, Video CD, CD-Audio (CD-DA),
CD-R/CD-RW (MP3, JPEG, CD-DA, Video CD
formatted discs)
Video interface
Output:
RCA: CVBS: 1 Vp-p Zout: 75 ohm
S-Video: Y: 1 Vp-p, C: 0.286 Vp-p
Zout: 75 ohm
RCA (YP
BPR): Y: 1 Vp-p, PB: 0.7 Vp-p, PR: 0.7 Vp-p
Zout: 75 ohm
Audio interface
Output:
RCA: Standard: 309 mVrms, FS: 2 Vrms at 1 kHz
Zout: less than 1 k≠, Load: 10 k≠
Digital Audio: Optical Output connector
(PCM, Dolby Digital, DTS)
Video data
Horizontal resolution: More than
XP: 500 lines SP: 500 lines
LP: 500 lines EP: 250 lines
Signal to Noise Ratio: More than 45 dB
Frequency Response: XP, SP: 0 dB ±3 dB at 4 MHz (0 dB at 0.1 MHz),
(Fine mode)
LP, EP: 0 dB ±3 dB at 2 MHz (0 dB at 0.1 MHz),
(Fine mode)
Audio data
Dynamic Range: Rec/PB: more than 90 dB
DVD-Video PB (with LPCM): more than 96 dB
CD PB: more than 96 dB
Frequency Response: XP, SP, LP, EP (6H mode): 20 Hz to 20 kHz (0 dB ±3 dB)
EP (8H mode): 20 Hz to 12 kHz (0 dB ±3 dB)
Cross Talk: More than 60 dB at 1 kHz
LASER Specification
Class 1 LASER Product
Wave Length:
795 nm, 662 nm
Laser Power:
No hazardous radiation is emitted with safety
protection
∫VHS
Recording format VHS Video Cassette System Standard with FM audio
Heads 4 helical scan heads for video
2 helical scan heads for FM audio
1 fixed head for Normal audio
Recording modes/
recording time
NTSC SP: 33.35 mm/s, 120 min
NTSC EP: 11.12 mm/s, 360 min
(with T-120 cassette)
others FF/REW: approx. 54 s,
Jet REW: approx. 36 s (with T-120 cassette)
Video data
Horizontal resolution: More than 200 lines
Signal to Noise Ratio: More than SP: 40 dB
EP: 40 dB
Frequency Response: SP, EP: j4.5 to 4.0 dB at 2 MHz (0 dB at 0.1 MHz)
Audio data
Dynamic Range: Hi-Fi: more than 90 dB
Frequency Response: Hi-Fi: 20 Hz to 20 kHz (0 dB ±3 dB)
Normal SP: 80 Hz to 8 kHz (0 dB ±4 dB)
Normal EP: 80 Hz to 4 kHz (j1 dB ±5 dB)
Signal to Noise Ratio: Hi-Fi: more than 65 dB
Normal SP: more than 43 dB
Normal EP: more than 41 dB
Cross Talk: More than 50 dB at 1 kHz (Hi-Fi)
Wow and Flutter: Hi-Fi: less than 0.005%
Normal SP: 0.2% ma x
Normal EP: 0.4% ma x
∫DVD/VHS Common
Video interface
TV system: NTSC
Input:
L1:
RCA: CVBS: 1 Vp-p Zin: 75 ohm
S-Video: Y: 1 Vp-p, C: 0.286 Vp-p
Zin: 75 ohm
L2:
RCA: CVBS: 1 Vp-p Zin: 75 ohm
S-Video: Y: 1 Vp-p, C: 0.286 Vp-p
Zin: 75 ohm
Output:
RCA: CVBS: 1 Vp-p Zout: 75 ohm
Audio interface
Input:
L1:
RCA: Standard: 309 mVrms, FS: 2 Vrms at 1 kHz
Zin: 22 k≠
L2:
RCA: Standard: 309 mVrms, FS: 2 Vrms at 1 kHz
Zin: 22 k≠
Output:
RCA:
DVD: Standard: 309 mVrms, FS: 2 Vrms at 1 kHz
Zout: less than 1 k≠, Load: 10 k≠
VHS: 309 mVrms
Zout: less than 1 k≠, Load: 10 k≠
Tuner RF
Tuner system/
Channel coverage:
NTSC-M
VHF: 2 ch to 13 ch 75 ohm
UHF: 14 ch to 69 ch 75 ohm
CATV: 5A & A-5 ch to EEE ch 75 ohm
One tuner (DVD and VCR common use)
RF converter: Provide 3ch or 4ch 75 ohm
Dimensions Approx. 430 mm (W)k89 mm (H)k352 mm (D)
[Approx. 16
15
/
16
q (W)k3
9
/
16
q (H)k13
7
/
8
q (D)]
Mass Approx. 5.8 kg (12.79 lbs.)
Operating Temperature 5oC to 40oC (41oF to 104oF)
Operating Humidity 35% to 80% RH (no condensation)
Reference
