Panasonic DMR-EZ48VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
PP27501 K1KA10B00196 CONNECTOR(10P) 1
QR27501 B1GBCFJJ0040 TRANSISTOR 1
QR27503 B1GBCFJJ0040 TRANSISTOR 1
QR27505 B1GBCFJJ0040 TRANSISTOR 1
R27501 ERJ3GEYJ271V 1/10W 270 1
R27502 ERJ3GEYJ152V 1/10W 1.5K 1
R27503 ERJ3GEYJ391V 1/10W 390 1
R27505 ERJ3GEYJ391V 1/10W 390 1
R27508 ERJ3GEYJ152V 1/10W 1.5K 1
R27509 ERJ3GEYJ152V 1/10W 1.5K 1
R27516 ERJ3GEYJ272V 1/10W 2.7K 1
R27517 ERJ3GEYJ222V 1/10W 2.2K 1
R27532 ERJ3GEYJ222V 1/10W 2.2K 1
S27501 EVQ11G07K SWITCH,OPEN/CLOSE 1
S27502 EVQ11G07K SWITCH,CH DOWN 1
S27503 EVQ11G07K SWITCH,STOP 1
S27504 EVQ11G07K SWITCH,CH UP 1
S27505 EVQ11G07K SWITCH,PLAY 1
S27506 EVQ11G07K SWITCH,REC 1
S27507 EVQ11G07K SWITCH,D2V 1
S27508 EVQ11G07K SWITCH,V2D 1
S27509 EVQ11G07K SWITCH,DRIVE
SELECT
1
S27510 EVQ11G07K SWITCH,RESET 1
Q VEP73153A DV/SD/USB P.C.B. 1 (RTL)
C66801 ECJ1VB0J105K 6.3V 1U 1
C66803 ECJ1VB0J105K 6.3V 1U 1
C66804 ECJ1VC1H471J 50V 470P 1
C66805 F1H1C104A090 16V 0.1U 1
C66806 F1H1C104A090 16V 0.1U 1
C66807 F1H1C104A090 16V 0.1U 1
C66808 F1H1C104A090 16V 0.1U 1
C66809 F1J0J106A013 6.3V 10U 1
C66810 F1H1C104A090 16V 0.1U 1
C66811 F1H1C104A090 16V 0.1U 1
C66812 F1H1H150A799 50V 15P 1
C66813 F1H1C104A090 16V 0.1U 1
C66814 ECJ1VC1H270J 50V 27P 1
C66815 F1H1C104A090 16V 0.1U 1
C66816 F1H1C104A090 16V 0.1U 1
C66817 F1H1C104A090 16V 0.1U 1
C66818 F1H1C104A090 16V 0.1U 1
C66819 F1H1C104A090 16V 0.1U 1
C66820 F1H1C104A090 16V 0.1U 1
C66821 F1H1C104A090 16V 0.1U 1
C66823 F1J0J106A014 6.3V 10U 1
C66826 F1H1A225A051 10V 22U 1
C66828 F1H1C104A090 16V 0.1U 1
C66829 F1H1C104A090 16V 0.1U 1
D66801 B0ECKP000002 DIODE 1
IC66801 C0DBGGF00001 IC 1
IC66802 C1CB00002799 IC 1
IC66803 C0DBZHE00024 IC 1
LB66801 ERJ3GEY0R00V 1/10W 0 1
LB66802 J0JGC0000020 COIL 1
P66801 K1KA06AA0231 CONNECTOR(6P) 1
P66802 K1MN07AA0003 CONNECTOR(7P) 1
P66803 K1FY104B0006 CONNECTOR(4P) 1
P66804 K1FY104B0011 USB CONNECTOR 1
P66805 K1NA09E00099 SD CARD CONNECTOR 1
R66801 ERJ3RBD123V 1/16W 12K 1
R66802 ERJ3GEYJ105V 1/10W 1M 1
R66803 ERJ3GEY0R00V 1/10W 0 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R66804 ERJ3GEYJ104V 1/10W 100K 1
R66805 ERJ3GEYJ103V 1/10W 10K 1
R66806 ERJ3GEYJ330V 1/10W 33 1
R66807 ERJ3GEYJ103V 1/10W 10K 1
R66808 ERJ3GEYJ330V 1/10W 33 1
R66809 ERJ3GEY0R00V 1/10W 0 1
R66810 ERJ3GEY0R00V 1/10W 0 1
R66811 ERJ3GEYJ330V 1/10W 33 1
R66812 ERJ3GEYJ330V 1/10W 33 1
R66813 ERJ3GEYJ330V 1/10W 33 1
R66814 ERJ3GEYJ103V 1/10W 10K 1
R66815 ERJ3GEYJ104V 1/10W 100K 1
R66816 ERJ3GEYJ330V 1/10W 33 1
R66817 ERJ3GEYJ473V 1/10W 47K 1
R66818 ERJ3GEY0R00V 1/10W 0 1
X66801 H0J240500042 CRYSTAL OSCILLATOR 1
Q VEP09150A DIGITAL I/F P.C.B. 1 (RTL)(P)
Q VEP09150B DIGITAL I/F P.C.B. 1 (RTL)(PC)
C1101 ECQU2A224MLC 0.22U 1
C1104 ECQU2A683MLC 0.068U 1
C1105 F1B2G1020002 1000P 1
C1106 F1B2G1020002 1000P 1
C1107 F2B2E2210011 250V 220U 1
C1108 F1B2G1020002 1000P 1
C1120 F2A1E1010103 25V 0.01U 1
C1121 F1B3A332A008 3300P 1
C1122 ECJ1VB1H102K 50V 1000P 1
C1123 ECJ1VC1H101J 50V 100P 1
C1124 F1H1H222A798 50V 2200P 1
C1200 ECJ1VB1A224K 10V 0.22U 1
C1201 ECJ1VB1C473K 16V 0.047U 1
C1240 F2A1C1520021 16V 1500U 1
C1241 F2A1C1520021 16V 1500U 1
C1242 F2A1C1020095 16V 1000U 1
C1260 F2A1C4710079 16V 470U 1
C1261 F1H1C105A095 16V 1U 1
C1262 F1H1C104A090 16V 0.1U 1
C1263 F1H1C104A090 16V 0.1U 1
C1264 ECJ1VC1H270J 50V 27P 1
C1266 ECJ1VB1H103K 50V 0.01U 1
C1268 F2A1A6810022 10V 680U 1
C1270 F2A1A1010072 10V 100U 1
C1280 F2A1A1010072 10V 100U 1
C1281 F1H1A105A028 10V 1U 1
C1282 F2A1A1010072 10V 100U 1
C1283 ECJ1VB1C333K 16V 0.033U 1
C1290 F1H1A105A028 10V 1U 1
C1291 F2A1A1010072 10V 100U 1
C1292 F2A1A1010072 10V 100U 1
C1300 F2A1C4710079 16V 470U 1
C1301 F1H1C105A095 16V 1U 1
C1302 F1H1C104A090 16V 0.1U 1
C1303 F1H1C104A090 16V 0.1U 1
C1304 ECJ1VC1H270J 50V 27P 1
C1306 ECJ1VB1H103K 50V 0.01U 1
C1308 F2A1A6810022 10V 680U 1
C1310 F2A1A1010072 10V 100U 1
C1340 F1H1A105A028 10V 1U 1
C1341 F2A1A1010072 10V 100U 1
C1342 ECJ1VB1C333K 16V 0.033U 1
C1343 F2A1A1010072 10V 100U 1
C7301 F2A0J220A878 6.3V 22U 1
C7302 F2A1H4R7B033 50V 4.7U 1
C7304 F2A0J220A878 6.3V 22U 1
C7305 F2A1H4R7B033 50V 4.7U 1
C7306 F2A1H4R7B033 50V 4.7U 1
C7308 ECJ1VB1C473K 16V 0.047U 1
C7310 F2A0J470A824 6.3V 47U 1
C7311 ECJ1VB1H103K 50V 0.01U 1
C7312 F1H1C104A090 16V 0.1U 1
121
DMR-EZ48VP / DMR-EZ48 VPC / DMR-EZ485VP
