Panasonic DMR-EZ48VP

Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*“(IA), (IB)”, marks in Remarks indicate languages of
instruction manuals. [(IA): English, (IB): Canadian French]
*All parts are supplied by PAVCSG.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
Q VEP06G41A MAIN P.C.B. 1 (RTL)
C2001 ECJ1VC1H330J 50V 33P 1
C2002 ECJ1VB0J105K 6.3V 1U 1
C2003 ECJ1VF1A105Z 10V 1U 1
C2051 F1J0J106A014 6.3V 10U 1
C2052 F1J0J106A014 6.3V 10U 1
C2053 F2A1C1000021 16V 10U 1
C2054 ECJ1VB1H392K 50V 3900P 1
C2055 ECJ1VF1C104Z 16V 0.1U 1
C2099 F1H1H681A799 50V 0.68U 1
C2501 ECJ1VF1C104Z 16V 0.1U 1
C2502 F2A0J101A825 6.3V 100U 1
C2504 ECJ1VB1E223K 25V 0.022U 1
C2505 ECJ1VB1E223K 25V 0.022U 1
C2506 ECJ1VB1A224K 10V 0.22U 1
C2507 ECJ1VB1H102K 50V 1000P 1
C2508 ECJ1VB1H182K 50V 1800P 1
C2509 F2A1C220B100 16V 22U 1
C2510 F1H1C104A090 16V 0.1U 1
C2511 F1H1C104A090 16V 0.1U 1
C2512 F1H1C104A090 16V 0.1U 1
C2513 ECJ1VF1A105Z 10V 1U 1
C2515 ECJ1VB1H103K 50V 0.01U 1
C2518 ECJ1VB1H103K 50V 0.01U 1
C2519 ECJ1VB1H103K 50V 0.01U 1
C2551 ECJ1VB1C473K 16V 0.047U 1
C2552 ECJ1VB1C683K 16V 0.068U 1
C2561 ECJ1VB1C683K 16V 0.068U 1
C2562 ECJ1VB1C473K 16V 0.047U 1
C2571 F2A1C2210095 16V 220U 1
C3001 ECJ1VC1H151J 50V 150P 1
C3002 F1H1C104A090 16V 0.1U 1
C3003 F1H1C104A090 16V 0.1U 1
C3004 F2A1C100B099 16V 10U 1
C3005 F1H1H220A799 50V 22P 1
C3006 F1H1C104A090 16V 0.1U 1
C3007 ECJ1VB1H103K 50V 0.01U 1
C3008 F2A1H4R7B033 50V 4.7U 1
C3009 ECJ1VB0J105K 6.3V 1U 1
C3010 ECJ1VB0J105K 6.3V 1U 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C3011 F1H1C104A090 16V 0.1U 1
C3012 F2A0J470A824 6.3V 47U 1
C3013 F2A1C100B099 16V 10U 1
C3014 F1H1C104A090 16V 0.1U 1
C3015 ECJ1VB0J105K 6.3V 1U 1
C3016 F1H1C104A090 16V 0.1U 1
C3017 F1H1C104A090 16V 0.1U 1
C3019 F1H1C104A090 16V 0.1U 1
C3020 F2A1H3R3B032 50V 3.3U 1
C3021 F2A1V100A824 35V 10U 1
C3023 ECJ1VB1H103K 50V 0.01U 1
C3024 ECJ1VC1H331J 50V 330P 1
C3025 ECJ1VB1H103K 50V 0.01U 1
C3028 F2A1H4R7B033 50V 4.7U 1
C3029 F2A1HR47B032 50V 47U 1
C3030 ECJ1VB1E223K 25V 0.022U 1
C3031 ECJ1VB1C333K 16V 0.033U 1
C3032 F2A1H4R7B033 50V 4.7U 1
C3033 F1H1C104A090 16V 0.1U 1
C3034 F2A1H2R2B032 50V 2.2U 1
C3035 F1H1H472A798 50V 4700P 1
C3036 F2A0J470A824 6.3V 47U 1
C3037 F1H1C104A090 16V 0.1U 1
C3038 ECJ1VC1H040C 50V 4P 1
C3039 F2A1H1R0B032 50V 1U 1
C3040 ECJ1VB1H103K 50V 0.01U 1
C3041 ECJ1VB1H103K 50V 0.01U 1
C3044 F1H1C104A090 16V 0.1U 1
C3048 ECJ1VB1H103K 50V 0.01U 1
C3050 F1H1C104A090 16V 0.1U 1
C3053 F1H1C104A090 16V 0.1U 1
C3074 F1H1C104A090 16V 0.1U 1
C3701 F1H1C104A090 16V 0.1U 1
C3703 F1H1C104A090 16V 0.1U 1
C3705 F2A0J102A833 6.3V 1000U 1
C3706 F1H1C104A090 16V 0.1U 1
C3707 F2A1V470A831 35V 47U 1
C3708 F1H1C104A090 16V 0.1U 1
C3709 F2A1V470A831 35V 47U 1
C3710 ECJ1VB0J105K 6.3V 1U 1
C3711 ECJ1VB0J105K 6.3V 1U 1
C3712 ECJ1VF1C104Z 16V 0.1U 1
C3713 ECJ1VB0J105K 6.3V 1U 1
C3714 ECJ1VB1H103K 50V 0.01U 1
C3715 ECJ1VB0J105K 6.3V 1U 1
C3716 ECJ1VB0J105K 6.3V 1U 1
C3717 F2A1H1R0B040 50V 1U 1
C3718 F2A1H1R0B040 50V 1U 1
C3721 F2A1C100B110 16V 10U 1
C3722 ECJ1VB0J105K 6.3V 1U 1
C3724 ECJ1VB0J105K 6.3V 1U 1
C3725 ECJ1VB0J105K 6.3V 1U 1
C3726 ECJ1VB0J105K 6.3V 1U 1
C3727 ECJ1VF1H103Z 50V 0.01U 1
C3728 ECJ1VF1C104Z 16V 0.1U 1
C3729 ECJ1VB0J105K 6.3V 1U 1
C3730 ECJ1VF1C104Z 16V 0.1U 1
C3731 F1H1C104A090 16V 0.1U 1
C3733 F2A0J102A833 6.3V 1000U 1
C3734 F2A0J102A833 6.3V 1000U 1
C3735 ECJ1VF1H103Z 50V 0.01U 1
C3736 F2A0J471A832 6.3V 470U 1
C3737 F2A0J471A832 6.3V 470U 1
C3738 F2A0J102A833 6.3V 1000U 1
C3739 ECJ1VF1C104Z 16V 0.1U 1
C3740 ECJ1VF1H103Z 50V 0.01U 1
C3741 ECJ1VF1C104Z 16V 0.1U 1
C3742 ECJ1VF1C104Z 16V 0.1U 1
C4001 ECQB1H333JF3 50V 0.033U 1
C4004 ECJ1VB1H182K 50V 1800P 1
C4005 F2A0J220A878 6.3V 22U 1
