Panasonic DMR-EZ48VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
28 RYP1418D-K FRONT PANEL ASS’Y
1
1 (EZ485V)
28-1 RGU2475-S DUBBING BUTTON 1
28-2 RGU2563-K OPERATION BUTTON 1
28-3 RKF0799-K BLINDER PANEL 1
28-4 RKF0800-K TRAY DOOR 1
28-5 RKF0801-K1 DOOR 1
28-6 RKW0781B-Q DUB WINDOW 1
28-7 RMB0870 TRAY DOOR SPRING 1
28-8 RMC0689 EARTH SPRING(T) 1
28-9 RMC0744 EARTH PLATE 1
28-11 VMB2521-J BLINDER SPRING 1
29 VEE1D23 WIRE WITH
CONNECTOR
1
30 VEE1E19 WIRE WITH
CONNECTOR
1
31 RHD30113-1K SCREW 4
32 RHD30119-L SCREW 3
33 RKM0572-K TOP COVER 1
34 VWJ1935 FFC(7P) 1
35 VWJ2003 FFC 1
36 VWJ2004 FFC 1
37 XSN3+4FJ SCREW 2
38 XTV26+6FFJ SCREW 1
39 RHD30111-3 SCREW 1
40 VHD1092-1 SCREW 1
41 VKC0295 HOLDER 3
42 VWJ1933-2 FFC(40P) 1
101 VEG1697KIT RDD CYLINDER ASS’Y 1
101-1 VMD5464 FPC HOLDER 1
102 VEM0800T CAPSTAN MOTOR 1
103 L1AG00000011 FE HEAD ASS’Y 1
104 VDB1431 TENSION ARM BOSH 1
105 VDG1686 INTERMEDIATE GEAR 1
106 VDG1685 MAIN CAM GEAR 1
107 VDG1512 IDLER GEAR 2
108 VDG1514 CHANGE GEAR 1
109 VDR0372A REEL TABLE 2
110 VDV0391 CAPSTAN BELT 1
111 VEM0797 LOADING MOTOR 1
112 VMB3550A CHANGING GEAR
SPRING
1
113 VMD4987 WORM SHAFT HOLDER 1
114 VMD5466 OPENER PIECE 1
115 VMD4253 LED PRISM 1
116 VML3934 MAIN LEVER 1
117 VML3933 PINCH CHARGE ARM 1
118 VML3632 IDLER ARM 1
119 VMX3092 P4 CAP 1
120 VXA7105 S SHAFT HOLDER 1
121 VXA7106 T SHAFT HOLDER 1
122 L1AE00000044 AC HEAD ASS’Y 1
122-1 VHD1066-2 SCREW 2
122-2 VHD1185 SCREW 1
124 VXL3107 S LOADING ARM 1
125 VXL3108 T LOADING ARM 1
126 VXL3109-7 PINCH ARM 1
127 VXL3110 P5 ARM 1
128 VXL3111-1 TENSION ARM 1
129 VXL3252 S BRAKE ARM 1
130 VXL3343 T BRAKE ARM 1
130-1 VMB3548 T BRAKE SPRING 1
131 VXL3124 CHANGING LEVER 1
132 VXP2133 CENTER CLUTH 1
133 VXP2168 TORQUE CLUTCH 1
134 VMA0L25 TOP PLATE 1
135 VMD5468 SIDE PLATE(L) 1
136 VMD5469 SIDE PLATE(R) 1
137 VXA8265 CASSETTE HOLDER
ASS’Y
1
138 VXL3160 MAIN SHAFT 1
139 VDG1684 SECTOR GEAR 1
141 VML3706 OPENER LEVER 1
142 VHD1044-1 SCREW 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
143 XYN3+C4FJ SCREW 1
144 XTN26+7JFJ SCREW 3
145 XTV26+5FFJ SCREW 2
146 XTV26+8FFJ SCREW 2
148 VHD1117-1 SCREW 3
149 VMX2208 WASHER 1
150 VMX3196 WASHER 1
151 VMX2699 WASHER 1
152 VMX3196 WASHER 1
A1 K2CB2CB00018 AC CORD 1
A2 K2KA6BA00004 AV CORD 1
A3 K2KZ2BA00001 RF COAXIAL CABLE 1
A4 N2QAYB000197 REMOTE CONTROL
ASS’Y
1
A4-1 100300037800 BATTERY COVER 1
A5 RPQF0220-2 ACCESSORY BOX 1 (EZ48V)
A5 RPQF0254 ACCESSORY BOX 1 (EZ485V)
A6 RPFC0031-B POLYETHYLENE BAG 1
A7 RQT9056-P OPERATING
INSTRUCTIONS
1 (IA)
A7 RQT9057-C OPERATING
INSTRUCTIONS
1 (EZ48VPC)(IB)
A8 K1HA19DA0007 HDMI CABLE 1 (EZ485V)
PC1 RPG8415-1 PACKING CASE 1 (EZ48VP)
PC1 RPG8416-1 PACKING CASE 1 (EZ48VPC)
PC1 RPG8545 PACKING CASE 1 (EZ485V)
PC2 RPN2036A CUSHION(A) 1
PC3 RPN2036B CUSHION(B) 1
PC4 RPF0459 POLYETHYLENE BAG 1
PC5 RPN1994 FRONT PAD 1
124
DMR-EZ48VP / DMR-EZ48 VPC / DMR-EZ485VP
