Panasonic DMR-EZ48VP

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R1121 ERJ6GEYJ100V 1/8W 10 1
R1122 ERDS2TJ221T 1/4W 220 1
R1123 ERJ3GEYJ103V 1/10W 10K 1
R1124 ERJ3GEYJ103V 1/10W 10K 1
R1125 ERX2SZJR10E 2W 10 1
R1126 ERJ3RBD153V 1/16W 15K 1
R1127 ERJ3RBD102V 1/16W 1K 1
R1128 ERJ3RBD182V 1/16W 1.8K 1
R1129 ERJ3RBD682V 1/16W 6.8K 1
R1200 ERJ3GEYJ102V 1/10W 1K 1
R1201 ERJ3GEYJ271V 1/10W 270 1
R1203 ERJ3GEYJ222V 1/10W 2.2K 1
R1204 ERJ3GEYJ103V 1/10W 10K 1
R1206 ERJ3RBD272V 1/16W 2.7K 1
R1207 ERJ3GEY0R00V 1/10W 0 1
R1208 ERJ3RBD561V 1/16W 560 1
R1209 ERJ3RBD103V 1/16W 10K 1
R1260 ERJ3GEYJ333V 1/10W 33K 1
R1261 D1BFR033A010 1/2W 0.033 1
R1262 ERJ3RBD681V 1/16W 680 1
R1263 ERJ3RBD133V 1/16W 13K 1
R1264 ERJ3RBD362V 1/16W 3.6K 1
R1280 ERJ3RBD102V 1/16W 1K 1
R1281 ERJ3RBD223V 1/16W 22K 1
R1282 ERJ3RBD113V 1/16W 11K 1
R1290 ERJ3RBD362V 1/16W 3.6K 1
R1291 ERJ3RBD683V 1/16W 68K 1
R1292 ERJ3RBD243V 1/16W 24K 1
R1300 ERJ3GEYJ333V 1/10W 33K 1
R1301 D1BFR0270001 1/2W 0.027 1
R1302 ERJ3RBD821V 1/16W 820 1
R1303 ERJ3RBD103V 1/16W 10K 1
R1304 ERJ3RBD472V 1/16W 4.7K 1
R1340 ERJ3RBD102V 1/16W 1K 1
R1341 ERJ3RBD393V 1/16W 39K 1
R1342 ERJ3RBD113V 1/16W 11K 1
R7301 ERJ3GEYJ101V 1/10W 100 1
R7302 ERJ3GEYJ101V 1/10W 100 1
R7304 ERJ3GEY0R00V 1/10W 0 1
R7305 ERJ3GEY0R00V 1/10W 0 1
R7306 ERJ3GEYJ472V 1/10W 4.7K 1
R7307 ERJ3GEYJ102V 1/10W 1K 1
R7308 ERJ3GEY0R00V 1/10W 0 1
R7801 ERJ3GEYJ681V 1/10W 680 1
R7802 ERJ3GEYJ104V 1/10W 100K 1
R7803 ERDS2TJ102T 1/4W 1K 1
R7804 ERJ3GEY0R00V 1/10W 0 1
R7805 ERJ3GEY0R00V 1/10W 0 1
R7901 ERJ3GEYJ472V 1/10W 4.7K 1
R7902 ERJ3GEYJ562V 1/10W 5.6K 1
R7903 ERJ3GEYJ472V 1/10W 4.7K 1
R7904 ERJ3GEYJ470V 1/10W 47 1
R7905 ERJ3GEYJ473V 1/10W 47K 1
R7906 ERJ3GEYJ473V 1/10W 47K 1
R7907 ERDS2TJ1R0T 1/4W 1.0 1
R7908 ERDS2TJ331T 1/4W 330 1
R37503 ERJ3GEYJ473V 1/10W 47K 1
R37504 ERJ3GEYJ473V 1/10W 47K 1
R37594 ERJ3GEYJ303V 1/10W 30K 1
R37595 ERJ3GEYJ821V 1/10W 820 1
R37596 ERJ3GEYJ153V 1/10W 15K 1
T1101 G4D2A0000292 TRANSFORMER 1
T7901 G4D1A0000115 TRANSFORMER 1
TU7801 ENG56E02G1F TUNER,VHF/UHF 1
VA1101 ERZVA5V471 VARISTOR 1
VA1102 ERZVA5V471 VARISTOR 1
W300 ERJ3GEY0R00V 1/10W 0 1
W301 ERJ3GEY0R00V 1/10W 0 1
W302 ERJ3GEY0R00V 1/10W 0 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
W303 ERJ3GEY0R00V 1/10W 0 1
W304 ERJ3GEY0R00V 1/10W 0 1
W305 ERJ3GEY0R00V 1/10W 0 1
W306 ERJ3GEY0R00V 1/10W 0 1
W307 ERJ3GEY0R00V 1/10W 0 1
W308 ERJ3GEY0R00V 1/10W 0 1
W309 ERJ3GEY0R00V 1/10W 0 1
W310 ERJ3GEY0R00V 1/10W 0 1
W311 ERJ3GEY0R00V 1/10W 0 1
W312 ERJ3GEY0R00V 1/10W 0 1
W313 ERJ3GEY0R00V 1/10W 0 1
W314 ERJ3GEY0R00V 1/10W 0 1
W315 ERJ3GEY0R00V 1/10W 0 1
W316 ERJ3GEY0R00V 1/10W 0 1
W317 ERJ3GEY0R00V 1/10W 0 1
W318 ERJ3GEY0R00V 1/10W 0 1
W319 ERJ3GEY0R00V 1/10W 0 1
ZA1101 EYF52BCY FUSE HOLDER 1
ZA1102 EYF52BCY FUSE HOLDER 1
ZA1120 VSC5713-A EARTH PLATE 1
ZA1121 XYN3+J8FJ SCREW 1
ZA1240 VSC5984 HEAT SINK 1
ZA1241 XYN3+J8FJ SCREW 1
ZA1280 VSC5839-A HEAT SINK 1
ZA1281 XYN3+J8FJ SCREW 1
ZA1340 VSC5836-A EARTH PLATE 1
ZA1341 XYN3+J8FJ SCREW 1
ZJ37001 K9ZZ00001279 EARTH PLATE 1
ZJ37002 K9ZZ00001279 EARTH PLATE 1
ZJ37003 K9ZZ00001279 EARTH PLATE 1
ZJ37004 K9ZZ00001279 EARTH PLATE 1
ZA37005 K9ZZ00001279 EARTH PLATE 1
Q CASING/ACCESSORY/P
ACKING
1 VEP04927A FRONT(L)P.C.B. 1 (RTL)
2 VEP06G41A MAIN P.C.B. 1 (RTL)
3 VEP07B04A FRONT(R)P.C.B. 1 (RTL)
4 VEP09150A DIGITAL I/F P.C.B. 1 (RTL)
(EZ48VP/EZ485
V)
4 VEP09150B DIGITAL I/F P.C.B. 1 (RTL)
(EZ48VPC)
5 VEP73153A DV/SD/USB P.C.B. 1 (RTL)
6 RFKB79180C DIGITAL P.C.B. 1 (RTL)
7 L6FALCCH0002 FAN MOTOR 1
8 RGR0374A-E1 REAR PANEL 1 (EZ48VP)
8 RGR0374A-F1 REAR PANEL 1 (EZ48VPC)
8 RGR0374A-G REAR PANEL 1 (EZ485V)
9 RHD26054 SCREW 1
10 RHD30111-3 SCREW 15
11 RHD30119-L SCREW 9
12 RHD30148 SCREW 1
13 RHDC0023 SCREW 3
14 RKA0137-K FOOT RUBBER 2
15 RKA0178-X FOOT 2
16 RMA2044-1 DVD ANGLE 1
17 RMA2060 REAR ANGLE 1
18 RMC0708-1 EARTH SPRING 1
19 RMC0741 EARTH PLATE(T) 1
20 RMN0885 SPACER 1
21 RMX0354 MECHA SPACER(F) 1
22 RMX0355 MECHA SPACER(R) 1
23 RMX0390 PCB SUPPORT 2
24 RMX0398 FFC SPACER 1
25 RMX0411 PCB SUPPORT 1
26 RMZ0891 INSULATION SHEET 1
27 RHD26045-J SCREW 3
28 RYP1418-K FRONT PANEL ASS’Y
1
1 (EZ48V)
123
DMR-EZ48VP / DMR-EZ48 VPC / DMR-EZ485VP
