DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
U33 Finisher Saddle Staple Unit is not
installed
1) Is the saddle staple unit installed properly?
2) Saddle staple unit storage sensor connector is
shorted or broken.
3) Saddle staple unit storage sensor is defective.
4) Saddle unit CPU PCB connector is shorted or
broken.
5) Saddle unit CPU PCB is defective.
6) Finisher CPU PCB connector is shorted or
broken.
7) Finisher CPU PCB is defective.
8) LVPS connector is shorted or broken.
9) LVPS is defective.
10) CPU PCB connector (CN15) is shorted or broken.
U34 Finisher Saddle Unit Saddle Front Cover
open
1) Is the saddle front cover closed correctly?
2) Saddle front cover open / close sensor connector
is shorted or broken.
3) Saddle front cover open / close sensor is
defective.
4) Saddle unit CPU PCB connector is shorted or
broken.
5) Saddle unit CPU PCB is defective.
6) Finisher CPU PCB connector is shorted or
broken.
7) Finisher CPU PCB is defective.
8) LVPS connector is shorted or broken.
9) LVPS is defective.
10) CPU PCB connector (CN15) is shorted or broken.
U35 Finisher Saddle Unit Saddle Paper Exit
Cover open
1) Is the saddle paper exit cover closed correctly?
2) Saddle paper exit cover open/close sensor
connector is shorted or broken.
3) Saddle paper exit cover open/close sensor is
defective.
4) Saddle unit CPU PCB connector is shorted or
broken.
5) Saddle unit CPU PCB is defective.
6) Finisher CPU PCB connector is shorted or
broken.
7) Finisher CPU PCB is defective.
8) LVPS connector is shorted or broken.
9) LVPS is defective.
10) CPU PCB connector (CN15) is shorted or broken.
11) CPU PCB is defective.
oF Finisher over flow Too many copies in the finisher bin.
The paper must be removed and press the finisher
mode key.
Code Item Check Points
