8
RQT8791
Preparations
Preparations
1 Attaching the battery (When the unit is off)
The illustrations shown are of CGR-H711; however the steps for the battery included with
[DVD-LS82]
(CGR-H702 or CGR-H712) or CGR-H701 (optional) are the same.
Detaching
≥ Turn the unit off before detaching the battery pack.
When not using for long periods of time
≥ Remove the battery pack (➜ left).
(Even when the unit is turned off, there is a
small amount of voltage running through the
unit, and this may result in a malfunction.)
≥ Recharge the battery for re-use.
2 Recharging the battery
The battery is not charged at the time of purchase. Charge before initial use.
BE SURE TO READ THE CAUTION FOR THE AC MAINS LEAD ON PAGE 2
BEFORE CONNECTION.
Clicks into place
Check to make sure it is securely fastened
Bottom side of this unit
RELEASE
DETACH ATTACH
Battery pack
2
1
Press and hold
DC IN
DC IN 12 V
To
household
mains socket
AC adaptor
(included)
AC mains lead
(included)
≥ You can also use this unit without charging while
connecting the AC adaptor and the AC mains lead.
≥ You can also use this unit without charging while
connecting Car DC Adaptor (➜ page 19, Connecting
the included Car DC Adaptor).
To conserve power
This unit consumes 0.4 W of power even when turned
off. When the unit is not going to be used for a long time,
disconnect the AC mains lead from the household mains
socket.
The unit is in the standby condition (the [Í] indicator
lights) when the AC mains lead is connected. The
primary circuit is always “live” as long as the AC adaptor
is connected to an electrical outlet.
[Í] goes out ➜ lights
§
[CHG] lights ➜ goes out
§
Only when recharged with the unit
off.
Recharging time
:
➜ page 9, Approximate recharging
and play times
When finished, disconnect the AC
adaptor and the AC mains lead.
Í
CHG
Started
Finished
p2-31.fm Page 8 Monday, January 22, 2007 4:49 PM
