Panasonic ET-ELW21 - Specifications; Lens Dimensions

10-ENGLISH
Dimensions
(Unit: mm)
Model number Dimensions
ET-ELW21
166 (6-17/32")
φ108 (4-1/4")
φ102 (4-1/32")
Specications
Check the specifications of each projection lens, and use the appropriate lens for your
intended use.
Model No. ET-ELW21 ET-ELW20 ET-ELT22 ET-ELT23
Lens Type Short fixed lens Short zoom lens Long zoom lens
Ultra long
zoom lens
F value 2.0 1.8 to 2.3 1.8 to 2.3 1.8 to 2.3
Focal Length (f) 13.05 mm 20.4 to 27.6 mm 45.6 to 73.8 mm 73.9 to 117.1 mm
Dimensions
*1
Width 108 mm (4-1/4") 116 mm (4-9/16") 108 mm (4-1/4") 108 mm (4-1/4")
Height 108 mm (4-1/4") 116 mm (4-9/16") 108 mm (4-1/4") 108 mm (4-1/4")
Depth 166 mm (6-17/32") 196 mm (7-23/32") 197 mm (7-3/4") 196 mm (7-23/32")
Net Weight 1.08 k
]
(2.38 lbs) 1.20 k
]
(2.65 lbs) 1.18 k
]
(2.60 lbs) 1.20 k
]
(2.65 lbs)
*1: Excluding protrusions.
