5 Disassembly and Assembly Instructions
5.1. Disassembly Instructions
Ref. No. 1A Procedure 1A Removal of Fixation cover.
1. Remove four screws where tightening fixation cover.
2. Pull off the fixing cover assembly.
3. Once removing the fixing cover, the driving shaft assembly may come
out.
Ref. No. 1B Procedure 1A 1B Removal of Anvil.
1. Pull the anvil out from the fixation cover.
