High−level Instructions
3 − 23
Examples of hexadecimal digit copy
The following patterns of digit transfer are possible based on the specification of n.
S
D
(1) When hexadecimal digit 1 of the source is copied to hexadecimal digit 1 of the destination:
Specify n: H 0 0 3 (Short form: H3)
(2) When hexadecimal digit 3 of the source is copied to hexadecimal digit 0 of the destination:
(3) When multiple hexadecimal digits (hexadecimal digits 2 and 3) of the source are copied to multiple
hexadecimal digits (hexadecimal digits 2 and 3) of the destination:
(4) When multiple hexadecimal digits (hexadecimal digits 0 and 1) of the source are copied to multiple
hexadecimal digits (hexadecimal digits 2 and 3) of the destination:
(5) When 4 hexadecimal digits (hexadecimal digits 0 to 3) of the source are copied to 4 hexadecimal
digits (hexadecimal digits 0 to 3) of the destination:
S
D
S
D
S
D
S
D
3210
3210
3210
3210
3210
3210digit
3210digit
3210digit
3210digit
3210digit
digit
digit
digit
digit
digit
Specify n: H 1 0 1
Specify n: H 2 1 2
Specify n: H 2 1 0
Specify n: H 1 3 0
