High−level Instructions
3 − 65
Outline Adds two 32-bit data items and stores the result in the specified area.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P23 (PD+)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F23 D+ , DT 10 , DT 20 , DT 30
S1
D
Trigger
S2
R0
10
11
ST R 0
F 23 (D+)
DT 10
DT 20
DT 30
S1 32-bit equivalent constant or lower 16-bit area of 32-bit data (for augend)
S2 32-bit equivalent constant or lower 16-bit area of 32-bit data (for addend)
D Lower 16-bit area of 32-bit data (for result)
Operands
modifier
S1 A A A A A A A A A A N/A A A A
S2 A A A A A A A A A A N/A A A A
D N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F23
P23
(D+)
(PD+)
32-bit data addition
[(S1+1, S1) + (S2+1, S2) → (D+1, D)]
A: Available
N/A: Not Available
