High−level Instructions
3 − 75
Outline Multiplies two 16-bit data items.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instructions
are not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10 F30 *, DT 10 , DT 20, DT 30
S1
D
Trigger
S2
R0
10
11
ST R 0
F30 (*)
DT 10
DT 20
DT 30
S1 16-bit equivalent constant or 16-bit area (for multiplicand)
S2 16-bit equivalent constant or 16-bit area (for multiplier)
D Lower 16-bit area of 32-bit data (for result)
Operands
modifier
S1 A A A A A A A A A A A A A A
S2 A A A A A A A A A A A A A A
D N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F30
P30
(*)
(P*)
16-bit data multiplication
[S1 × S2 → (D+1, D)]
A: Available
N/A: Not Available
