Outline Adds two BCD data items that express 8-digit decimal numbers
(8-digit BCD H codes) and stores the result in the specified area.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P43 (PDB+)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F43 DB+ , DT10 , DT20 , DT30
S1
S2 D
Trigger
R0
10
11
ST R 0
F 43 (DB+)
DT 10
DT 20
DT 30
S1 8-digit BCD equivalent constant or lower 16-bit area for 8-digit BCD data (for
augend)
S2 8-digit BCD equivalent constant or lower 16-bit area for 8-digit BCD data (for
addend)
D Lower 16-bit area for 8-digit BCD data (for result)
Operands
modifier
S1 A A A A A A A A A A N/A K A A
S2 A A A A A A A A A A N/A K A A
D N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
F43
P43
(PDB+)
(DB+)
8-digit BCD data addition
[(S1+1, S1) + (S2+1, S2) → (D+1, D)]
A: Available
N/A: Not Available
K: K0 to K9
