High−level Instructions
3 − 117
Outline Divides one BCD data item that expresses an 8-digit decimal number
(8-digit BCD H code) by another (divisor).
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P53 (PDB%)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F53 DB% , DT10 , DT 20 , DT30
S1
D
Trigger
S2
R0
10
11
ST R 0
F 53 (DB%)
DT 10
DT 20
DT 30
S1 8-digit BCD equivalent constant or lower 16-bit area for 8-digit BCD data (for
dividend)
S2 8-digit BCD equivalent constant or lower 16-bit area for 8-digit BCD data (for
divisor)
D Lower 16-bit area for 8-digit BCD data (for quotient)
(Remainder is stored in special data registers DT9016 and DT9015 or
DT90016 and DT90015)
Operands
modifier
S1 A A A A A A A A A A N/A A A A
S2 A A A A A A A A A A N/A A A A
D N/A A A A A A A A A A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
F53
P53
(PDB%)
8-digit BCD data division
[(S1+1, S1)/(S2+1, S2) →
(D+1, D)… (DT9016, DT9015) or (DT90016, DT90015)]
(DB%)
A: Available
N/A: Not Available
K: K0 to K9
