High−level Instructions
3 − 119
Outline Adds 1 to BCD data that expresses a 4-digit decimal number (4-digit
BCD H code).
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P55 (PB+1)” is not available.
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
10
F55 B+1 , DT 0
D
Trigger
R0
10
11
ST R 0
F 55 (B+1)
DT 0
D 16-bit area for 4-digit BCD data to be increased by 1
Operands
Operand
Relay Timer/Counter Register
Index
register
Constant
Inde
x
Operand
WX WY WR
WL
(*1)
SV EV DT
LD
(*1)
FL
(*2)
IX
(*3)
IY
(*4)
K H
Index
modifier
D N/A A A A A A A A A A A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
Explanation of example
Adds 1 to the contents of data register DT0 when trigger R0 turns on.
Original data [D]: H9 (BCD)
+1
Result [D]: H10 (BCD)
BCD H code
····
Bit position
·····
DT0
15
000
12
0
11
000
8
0
7
000
4
0
3
100
0
1
0009
BCD H code
····
Bit position
·····
DT0
15
000
12
0
11
000
8
0
7
000
4
1
3
000
0
0
0010
F55
P55
(PB+1)
(B+1)
4-digit BCD data increment
[D + 1 → D]
A: Available
N/A: Not Available
