High−level Instructions
3 − 208
Outline Encodes the specified data.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P92 (PENCO)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F92 ENCO, DT10, H5 , DT20
S
D
Trigger
R20
n
10
11
ST R 20
F 92 (ENCO)
DT 10
H5
DT 20
S Starting 16-bit area to be encoded (source)
n 16-bit equivalent constant or 16-bit area to specify starting bit position and
number of bits to be encoded
D 16-bit area for storing encoded data (destination)
Operands
modifier
S A A A A A A A A A N/A N/A N/A N/A A
n A A A A A A A A A A A A A A
D N/A A A A A A A A A A A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F92
P92
(PENCO)
(ENCO)
Encode
A: Available
N/A: Not Available
