6.5.1 Installation of the Zoom Ring Unit and the Zoom Drive Pin
1. Install the Zoom Ring Unit and the Zoom Drive Pin.
2. 
6.5.2 Installation of the Mount Contact Unit and the Lens P.C.B.
1. Connect FPC of the Mount Connect Unit to connector.
2. Installation the Main P.C.B. with the Mount Contact Unit.
3. 
