1 Connect the AC adaptor (supplied with VW-BN1) to the DVD burner.
≥ You cannot supply power to the DVD burner from this unit.
2 Connect this unit to the AC adaptor and change the mode to .
3 Connect this unit to the DVD burner with the Mini AB USB Connection
Cable (supplied with VW-BN1).
A Mini AB USB Connection Cable (supplied with VW-BN1)
B DVD burner (optional)
≥ Insert the plugs as far as they will go.
4 Insert the disc in the DVD burner.
≥ Insert the DVD disc with the recording side down when using the VW-BN1.
5 Touch the desired item.
≥ [BURN DISC]: Refer to page 104 for how to copy discs.
≥ [PLAY DISC]: Refer to page 108 for how to play back the copied discs.
To terminate the connection with the DVD burner
Touch [EXIT].
≥ Disconnect the Mini AB USB Connection Cable from this unit.
