10
VQT3K07
Charging and recording time
∫ Charging/Recording time
≥ Temperature: 25 oC/humidity: 60%RH (When using AC adaptor)
≥ These times are approximations.
≥ The indicated charging time is for when the battery has been discharged completely.
Charging time and recordable time vary depending on the usage conditions such as
high/low temperature.
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping
recording, turning the unit on/off, moving the zoom lever etc.
≥ The batteries heat up after use or charging. This is not a malfunction.
HDC-SD40
Battery model number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
mode
Maximum
continuously
recordable time
Actual
recordable
time
Supplied battery/
VW-VBK180 (optional)
[3.6 V/1790 mAh]
2h25min
[HA], [HG],
[HX]
2h15min 1h10min
[iFrame] 2h40min 1h25min
HDC-TM40
Battery model number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
mode
Maximum
continuously
recordable time
Actual
recordable
time
Supplied battery/
VW-VBK180 (optional)
[3.6 V/1790 mAh]
2h25min
[HA], [HG],
[HX]
2h15min 1h10min
[iFrame] 2h40min 1h25min
Battery capacity indication
≥ The display changes as the battery capacity reduces.
####
If there is less than 3 minutes remaining, then will become red. If the battery
discharges, then will flash.
≥ The remaining battery capacity is displayed when using the Panasonic battery that you
can use for this unit. The actual time can vary depending on your actual use.
≥ When using the AC adaptor or batteries made by other companies, the remaining
battery capacity will not be shown.
