20.2.3. Digital Board Parts (KX-FP218FX)
R570 ERJ2GEJ684 680k
R572 ERJ2GEJ273X 27k
R574 ERJ2GEJ185 1.8M
R575 ERJ2GEJ103 10k
R577 ERJ2GEJ473 47k
R580 ERJ2GEJ335 3.3M
R581 ERJ2GEJ472X 4.7k
R583 ERJ2GEJ683 68k
R587 ERJ2GEJ273X 27k
R588 ERJ2GEJ333 33k
R589 ERJ2GEJ153 15k
R590 ERJ2GEJ332 3.3k
R591 ERJ2GEJ222 2.2k
R593 ERJ2GEJ224 220k
R594 ERJ2GEJ101 100
R595 ERJ2GEJ181 180
R596 ERJ2GEJ103 10k
R597 ERJ2GEJ103 10k
R601 ERJ2GEJ473 47k
R602 ERJ2GEJ101 100
R603 ERJ2GEJ272 2.7k
R604 ERJ2GEJ124 120k
R606 PQ4R18XJ220 22 S
R607 ERJ2GEJ124 120k
R608 ERJ2GEJ334 330k
R609 ERJ2GEJ473 47k
R613 ERJ2GEJ563 56k
R614 ERJ2GEJ682 6.8k
R617 ERJ2GEJ473 47k
R622 ERJ2GEJ332 3.3k
R624 ERJ2GEJ472X 4.7k
R626 ERJ2GEJ332 3.3k
R627 ERJ2GEJ272 2.7k
R628 ERJ2GEJ102 1k
R633 ERJ2GEJ472X 4.7k
R638 ERJ2GEJ472X 4.7k
R554 ERJ2GE0R00 0
R569 ERJ2GE0R00 0
R598 ERJ2GE0R00 0
R618 ERJ2GE0R00 0
R637 ERJ2GE0R00 0
R506 ERJ2GE0R00 0
L504 ERJ3GEY0R00 0
J503 ERJ2GE0R00 0
J504 ERJ2GE0R00 0
(COMPONENTS PARTS)
RA501 EXB38V103JV RESISTOR ARRAY
RA502 EXB28V101JX RESISTOR ARRAY
RA503 EXB28V101JX RESISTOR ARRAY
RA504 D1H84724A013 RESISTOR ARRAY S
(CRYSTAL OSCILLATORS)
X501 H0A327200147 CRYSTAL OSCILLATOR
X502 H2C240500006 CRYSTAL OSCILLATOR
X503 H0J322500006 CRYSTAL OSCILLATOR
Ref.
No.
Part No. Part Name & Description Remarks
PCB1 PFWP1FP218FX DIGITAL BOARD ASS'Y (RTL)
(ICs)
IC501 C1ZBZ0003300 IC
IC502 C0CBADD00009 IC
IC503 C3ABKC000034 IC
IC504 C0CBCBD00047 IC
IC505 C1CB00002325 IC
IC506 PFWIFP218FX I C ( R O M )
IC507 C3FBKC000135 IC
IC508 C0JBAS000185 IC
IC509 C0JBAA000393 IC
IC510 C1AB00002556 IC
IC511 C0ABEB000023 IC
IC512 C0JBAE000333 IC
Ref.
No.
Part No. Part Name & Description Remarks
(TRANSISTORS)
Q501 B1GBCFGG0028 TRANSISTOR(SI)
Q502 B1GBCFGG0028 TRANSISTOR(SI)
Q503 B1ABDF000025 TRANSISTOR(SI)
Q504 B1ABDF000025 TRANSISTOR(SI)
Q505 B1ABDF000025 TRANSISTOR(SI)
Q506 B1ABDF000026 TRANSISTOR(SI)
Q508 2SB1218ARL TRANSISTOR(SI)
Q509 B1ABDF000025 TRANSISTOR(SI)
Q510 B1ABDF000025 TRANSISTOR(SI)
Q513 B1GBCFJJ0048 TRANSISTOR(SI)
Q514 B1GBCFJJ0048 TRANSISTOR(SI)
Q515 B1ABDF000026 TRANSISTOR(SI)
(DIODE)
D501 MA111 DIODE(SI) S
(BATTERY)
BAT501 CR2032/H9B BATTERY !
(CAPACITORS)
C501 F2G0J4700032 47
C502 ECJ0EF1C104Z 0.1
C503 ECJ0EF1C104Z 0.1
C505 ECJ0EF1C104Z 0.1
C507 ECJ1VF1A105Z 1
C508 ECJ0EB1H102K 0.001
C509 ECJ1VF1A105Z 1
C510 ECJ0EB1H102K 0.001
C511 F2G0J4700032 47
C512 ECJ0EB1A104K 0.1
C513 ECJ0EB1H102K 0.001
C514 ECJ0EB1H102K 0.001
C516 ECJ0EB1H102K 0.001
C517 ECJ0EF1C104Z 0.1
C518 ECJ0EF1C104Z 0.1
C521 ECJ0EB1H102K 0.001
C522 ECJ0EB1H222K 0.0022
C523 ECJ0EF1C104Z 0.1
C524 ECJ0EF1C104Z 0.1
C525 ECJ0EC1H101J 100p
C526 ECJ0EF1C104Z 0.1
C527 ECJ0EF1C104Z 0.1
C528 ECJ0EF1C104Z 0.1
C529 ECJ0EF1C104Z 0.1
C530 ECJ0EF1C104Z 0.1
C531 ECJ0EF1C104Z 0.1
C532 ECJ0EF1C104Z 0.1
C533 ECJ0EF1C104Z 0.1
C534 ECJ0EB1A104K 0.1
C535 ECJ0EB1A104K 0.1
C536 ECJ0EC1H100D 10p
C538 ECJ0EF1C104Z 0.1
C539 ECJ0EC1H150J 15p
C540 ECJ0EF1C104Z 0.1
C541 ECJ0EF1C104Z 0.1
C542 ECJ0EF1C104Z 0.1
C543 ECJ0EF1C104Z 0.1
C544 ECJ0EF1C104Z 0.1
C545 ECJ0EF1C104Z 0.1
C546 ECJ0EB1H102K 0.001
C548 ECJ0EF1C104Z 0.1
C549 ECJ0EF1C104Z 0.1
C550 ECJ0EF1C104Z 0.1
C551 F2G0J4700032 47
C553 ECJ0EF1C104Z 0.1
C556 ECJ0EF1C104Z 0.1
C559 ECJ0EB1C103K 0.01
C561 ECJ0EB1A104K 0.1
C563 ECJ1VF1H104Z 0.1
C564 ECJ0EF1C104Z 0.1
C567 ECJ0EC1H560J 56p
C568 ECJ1VF1H104Z 0.1
C570 ECJ0EB1E472K 0.0047
C573 F2G1C1000014 10
C574 ECJ0EB1A273K 0.027
Ref.
No.
Part No. Part Name & Description Remarks
