KX-TES824BX/KX-TEM824BX
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
CABINET AND ELECTRICAL PARTS
22 ---------- PSYEES824BXM NAME PLATE (KX-TES824BX)
(Made in Malaysia)
1 5
22 ---------- PSYEEM824BXM NAME PLATE (KX-TEM824BX)
(Made in Malaysia)
1 5
ACCESSORIES AND PACKING MATERIALS
A6 PSQX3609ZCD PSQX4031ZCD INSTRUCTION BOOK, CD-ROM 1 *3 8 X J
A7 PSQX3412X PSQX3412V INSTRUCTION BOOK 1 *3 8 X J
PSQW2426Z ---------- LEAFLET FOR DISA MEMORY 0 *3 6 J
PSQW2380Z ---------- LEAFLET FOR 2 PORT
DOORPHONE CARD
0 *3 6 J
PSQW2385Z ---------- LEAFLET FOR 2 PORT
DOORPHONE CARD FOR USER
0 *3 6 J
PSQW2431Z ---------- LEAFLET FOR BV MEMORY 0 *3 6 J
P1 ---------- PSZKES824BXM PACKING CASE, CARTON BOX
ASS’Y (KX-TES824BX) (Made in
Malaysia)
1 5
P1 ---------- PSZKEM824BXM PACKING CASE, CARTON BOX
ASS’Y (KX-TEM824BX) (Made in
Malaysia)
1 5
MAIN BOARD PARTS
IC600, IC601 PSVIMT8816AP C1CB00001893 IC 2 *R 8 W
IC705 PSWIES824BX7 PSWIES824BX8 IC 1 *3 8 X J
IC705 PSWIES824BX8 PSWIES824BX9 IC 1 8 X K
CN1A to CN1C PQJJ1T004Z K2LB102B0059 JACK, TEL 3 *R 8 W
CN200A to
CN200H
PQJJ1T011Y K2LB104B0052 JACK, TEL 8 *R 8 W
C214 ECJ1VB0J225 ECJ1VB1A225K CAPACITOR, 2.2µF 1 8 X
C974 to C976,
C981 to C984
---------- ECUV1H104ZFV CAPACITOR, 0.1µF 7 *4 5 I
SUB BOARD PARTS
IC500 PSVIMT8816AP C1CB00001893 IC 1 *R 8 W
CN1A to CN1C PQJJ1T004Z K2LB102B0059 JACK, TEL 3 *R 8 W
CN200A to
CN200H
PQJJ1T011Y K2LB104B0052 JACK, TEL 8 *R 8 W
C214 ECJ1VB0J225 ECJ1VB1A225K CAPACITOR, 0.1µF 1 8 X
C875 to C883 ---------- ECUV1H104ZFV CAPACITOR, 0.1µF 9 *4 5 I
KX-TE82461X
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
ACCESSORIES AND PACKING MATERIALS
P2 ---------- PSZKE82461XM GIFT BOX (Made in Malaysia,
marked by L4)
1 5
P2 ---------- PSZKE82461XK GIFT BOX (Made in Malaysia,
marked by MK)
1 5
4
KX-TES824BX / KX-TEM824BX
