Panasonic KX-TES824BX - Page 5

Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
C15A,C15C ECUV1C104ZFV ECUV1H104ZFV CAPACITOR, 0.1µF 2 1 X
KX-TE82474X
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
ACCESSORIES AND PACKING MATERIALS
P4 ---------- PSZKE82474XM GIFT BOX (Made in Malaysia,
marked by L4)
1 5
P4 ---------- PSZKE82474XK GIFT BOX (Made in Malaysia,
marked by MK)
1 5
MAIN BOARD PARTS
CN200A to
CN200H
PQJJ1T011Y K2LB104B0052 JACK, TEL 8 *R 8 W
KX-TE82480X
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
ACCESSORIES AND PACKING MATERIALS
P4 ---------- PSZKE82480XM GIFT BOX (Made in Malaysia,
marked by L4)
1 5
P4 ---------- PSZKE82480XK GIFT BOX (Made in Malaysia,
marked by MK)
1 5
MAIN BOARD PARTS
IC701 PSVIMT8816AP C1CB00001893 IC 1 *R 8 W
CN1A,CN1B PQJJ1T004Z K2LB102B0059 JACK, TEL 2 *R 8 W
CN200A to
CN200H
PQJJ1T011Y K2LB104B0052 JACK, TEL 8 *R 8 W
C875 to C883,
C932
---------- ECUV1H104ZFV CAPACITOR, 0.1µF 10 *5 5 B
KX-TE82483X
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
ACCESSORIES AND PACKING MATERIALS
P4 ---------- PSZKE82483XM GIFT BOX (Made in Malaysia,
marked by L4)
1 5
P4 ---------- PSZKE82483XK GIFT BOX (Made in Malaysia,
marked by MK)
1 5
MAIN BOARD PARTS
IC500 PSVIMT8816AP C1CB00001893 IC 1 *R 8 W
CN1A to CN1C PQJJ1T004Z K2LB102B0059 JACK, TEL 3 *R 8 W
CN200A to
CN200H
PQJJ1T011Y K2LB104B0052 JACK, TEL 8 *R 8 W
C214 ECJ1VB0J225 ECJ1VB1A225K CAPACITOR, 2.2µF 1 8 X
C875 to C883 ---------- ECUV1H104ZFV CAPACITOR, 0.1µF 9 *6 5 B
R229 ERJ3GEYJ221 ERJ3GEY0R00 RESISTOR, 0Ω 1 7 V
KX-TE82491X
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
ACCESSORIES AND PACKING MATERIALS
P2 ---------- PSZKE82491XM GIFT BOX (Made in Malaysia,
marked by L4)
1 5
P2 ---------- PSZKE82491XK GIFT BOX (Made in Malaysia,
marked by MK)
1 5
KX-TE82492X
Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change
(Suffix)
Original (Old) New
ACCESSORIES AND PACKING MATERIALS
P2 ---------- PSZKE82492XM GIFT BOX (Made in Malaysia,
marked by L4)
1 5
P2 ---------- PSZKE82492XK GIFT BOX (Made in Malaysia,
marked by MK)
1 5
5
KX-TES824BX / KX-TEM824BX
