Page 19
The motor that does not stop if an emergency stop button is pressed
Even if an emergency stop button is pressed, the motor for the vacuum pump does not stop. This is
because the motor prevents picked-up components from dropping. Since it is installed inside the frame,
there is no danger that workers may receive an electric shock or become entangled with it.
Motor for the vacuum pump
The other motors (see below) stop if an emergency stop button is pressed.
1. XY-axis motor
2. Z
θ
-axis motor
3. Conveyor motor
4. Width-adjustment motor
E64C-E-XXA00-A04-01
E64C-AA00
E64C-009E
