Part Names
Use the area
inside the
undotted
circumference.
Cooking zone
• KY-C227D (Ø 190 mm)
• KY-A227D (Left: Ø 190 mm/Right: Ø 150 mm)
Use the area circled with this line
as a guideline.
Top plate
IR sensor
•
KY-C227D: Right & Left
•
KY-A227D: Left only
ECONAVI lamp
(KY-C227D only)
Left IH heater Right IH heater
Timer (P.17)
High temperature
caution light
• Illuminates when the
top plate becomes hot.
• Even after heating is
stopped or the power
is turned off, it keeps
flashing as long as the
top plate is hot.
Heating
menu
• For basic cooking, such as
simmering and stir-frying
(P.14)
Display area
Control area
* For explanation purpose, all
lights are illuminating in the
illustration below.
Operation panel
Congee
menu
(P.22)
Child safety lock key
• Locks all operations to prevent
misuse.
•
To activate or deactivate, touch
and hold the key for 3 seconds or
more after the power is turned on.
Main power switch
• Touch slightly long
to turn the power
on.
• Turns off
automatically in
about 1 minute
with no operation
performed in
power-on state.
Timer (P.17)
Heating
menu
• For basic cooking,
such as simmering
and stir-frying (P.14)
Child safety lock light
Main power light
必要なとき
Preparation
Luminous circle (KY-C227D only)
• Illuminates while heating,
and changes the brightness
according to the heat level.
• Even after heating is stopped or
the power is turned off, it keeps
flashing as long as the top
plate is hot.
Pan-frying
menu (P.18)
Deep-frying
menu
(P.20)
<
KY-C227D only
>
KY-C227D
To Next Page
