- 123 -
Connecting to other equipment
[PLAYBACK] mode: ¸
Playing Back Pictures on a TV Screen
(DMC-FS12PU/DMC-FS12PR/DMC-FS12GC)
(DMC-FS62GC)
• Please use the supplied AV cable.
(DMC-FS12P/DMC-FS12PC/DMC-FS12EG/DMC-FS12EP/DMC-FS12EB/DMC-FS12EE/
DMC-FS12GN)
(DMC-FS62EG/DMC-FS62EP/DMC-FS62EF/DMC-FS62EB/DMC-FS62EE/
DMC-FS62GN)
• Please use the optional AV cable (DMW-AVC1).
Preparations:
Set the [TV ASPECT]. (P28)
Turn this unit and the TV off.
1 Yellow: to the video input socket
2 White: to the audio input socket
A Align the marks, and insert.
B AV cable
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which will cause trouble.)
Connect the AV cable to the video input and the audio input sockets
on the TV.
Connect the AV cable to the [AV OUT] socket on the camera.
Turn the TV on and select external input.
Turn the camera on.
Playing back pictures using the AV cable
