- 7 -
Before Use
Names of the Components
1Flash (P48)
2 Lens (P129)
3 Self-timer indicator (P55)
AF assist lamp (P93)
4 LCD monitor (P46, 125)
5 Status indicator (P15, 26, 32)
6 [MENU/SET] button (P18)
7 [DISPLAY] button (P46)
8 [Q.MENU] (P23)/Delete (P44) button
9 [MODE] button (P30)
10 [REC]/[PLAYBACK] selector switch
(P20)
11 Cursor buttons
A: 3/Exposure compensation (P56)/
Auto bracket (P57)
B: 4/Macro mode (P53)
C: 2/Self-timer button (P55)
D: 1/Flash setting button (P48)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
114 109
5786
