Before Use
- 8 -
12 Camera ON/OFF switch (P18)
13 Zoom lever (P39)
14 Speaker (P99)
15 Microphone (P73)
16 Shutter button (P32, 73)
17 Intelligent auto button (P32)
18 Hand strap eyelet
• Be sure to attach the hand strap when
using the camera to ensure that you will
not drop it.
19 Lens barrel
20 [AV OUT/DIGITAL] socket (P114, 117,
123)
21 Tripod receptacle
• When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
22 Card/Battery door (P14, 15)
23 Release lever (P14)
24 DC coupler cover (P15)
• When using an AC adaptor, ensure that
the Panasonic DC coupler (optional) and
AC adaptor (optional) are used. For
connection details, refer to P15.
12 13
14 15 16 17
