VQT1W26
10
Before Use
Names of the Components
1 Flash (P38)
2 Lens (P91)
3 Self-timer indicator (P42)
AF assist lamp (P67)
4 LCD monitor (P37, 89)
5 Status indicator (P15, 23, 27)
6 [MENU/SET] button (P17)
7 [DISPLAY] button (P37)
8 [Q.MENU] (P21)/Delete (P35) button
9 [MODE] button (P26)
10 [REC]/[PLAYBACK] selector switch
(P18)
11 Cursor buttons
A: 3/Exposure compensation (P43)/
Auto bracket (P44)
B: 4/Macro mode (P41)/AF tracking
(P29, 64)
C: 2/Self-timer button (P42)
D: 1/Flash setting button (P38)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
DMC-FS15PPC-VQT1W26_eng.book 10 ページ ２００８年１２月８日 月曜日 午後７時１９分
