Recording pictures (basic)
29
VQT0S57
∫ Normal recording
The camera automatically sets the shutter
speed and the aperture value according to
the brightness of the subject.
1 1 Turn the camera on.
2 Select normal picture mode
[].
2 Aim the AF area 1 to the point
you want to focus and then press
the shutter button halfway.
• A: Press the shutter button halfway to
focus.
• The focus indication 2 is lit and then
the aperture value 3 and the shutter
speed 4 are displayed.
• When 5-area-focusing or 3-area-focusing
(High speed) is used for AF mode, the
AF area will not appear until the subject
is brought into focus. (P73)
3 Take a picture.
• B: Press the shutter button fully to take
the picture.
OFF
ON
1/25F2.8
When the
subject is not
focused
When the
subject is
focused
Focus
indication
Blink (green) On (green)
AF area White to red
or no AF area
Turns from
white to green
Sound Beeps 4 times Beeps 2 times
1/25F2.8
To Next Page
