Preparation
28
About the LCD Monitor/Viewfinder
1Switching the LCD monitor/Viewfinder
Press the [EVF/LCD] button to switch to the
screen you would like to turn on.
A LCD monitor (LCD)
B Viewfinder (EVF)
• When the LCD monitor turns on, the
Viewfinder turns off (and vice versa).
2Selecting the screen to be used
Press the [DISPLAY] button to switch to the
screen to be used.
• When the menu screen appears, the
[DISPLAY] button is not activated. During
9 pictures multi playback (P47) or
playback zoom (P48), the indications on
the screen can be turned on and off.
In recording mode (P32)
C Display
D Display with histogram
E Out-of-frame display
F Non-display (Recording guide line)
G Non-display
¢Histogram
In playback mode (P46)
H Display
I Display with recorded information and
histogram
J Non-display
DISPLAYEVF/LCD
2560
19
2560
19
100
_
0001
1/19
10:00 DEC. 1.2004
100
_
0001
1/19
10:00 DEC. 1.2004
F2.8 1/25
ISO
100
AUTO
2560
2560
