7.2. When Replacing the Main PCB
After replacing the MAIN PCB, be sure to achieve adjustment.
The adjustment instruction is available at “software download” on the “Support Information from NWBG-PAVC” web-site in “TSN
system”, together with Maintenance software.
7.3. Service Position
This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing.
Table S1 Extension Cable List
No. Parts No. Connection Form
1 VFK1976 FP9007 (MAIN) - TOP OPERATION UNIT 19PIN 0.5 FFC
2 VFK1783 P9004 (MAIN) - HOT SHOE UNIT 2PIN CABLE
3 VFK1980 P9002 (MAIN) - EVF UNIT 2PIN CABLE
4 VFK1461 FP9005 (MAIN) - EVF UNIT 20PIN 0.5 FFC
5 VFK1492 FP9004 (MAIN) - LCD HINGE UNIT 26PIN 0.5 FFC
6 VFK1576DC202 P9003 (MAIN) - FLASH SW UNIT 2PIN CABLE
7 VFK1480 FP9001 (MAIN) - MIC FPC UNIT 6PIN 0.5 FFC
8 VFK1441 FP9003 (MAIN) - SIDE OPERATION UNIT 8PIN 0.5 FFC
9 VFK1951 FP9008 (MAIN) - LENS FPC UNIT 39PIN 0.3 FFC
10 VFK1174 FP9002 (MAIN) - CCD UNIT 30PIN 0.5 FFC
11 VFK1576DC202 P9001 (MAIN) - AF ASSIST PCB 2PIN CABLE
12 VFK1576DSC03 P9006 (MAIN) - BATTERY CATCHER UNIT 3PIN CABLE
13 VFK1582A1225 FP9006 (MAIN) - FP8101 (FLASH) 12PIN 0.5 FFC
14 VFK1576DSC03 P9001 (FLASH) - FLASH UNIT 2PIN CABLE
15 VFK1576DC202 P9002 (FLASH) - FLASH UNIT 2PIN CABLE
To Next Page
